Cable Information
AC connector
The following cables can be used.
Conductor cross section rigid 1.5 mm
2
to 6 mm
2
Conductor cross section flexible 1.5 mm
2
to 6 mm
2
Stripping length 10 mm
Note
Press the orange levers, then plug in the cables.
To disconnect them, unplug the cables while pressing the orange levers.
Control connector
The following cables can be used.
Conductor cross section rigid 0.14 mm
2
to 1.5 mm
2
Conductor cross section flexible 0.14 mm
2
to 1.5 mm
2
2 conductors with same cross section, solid 0.08 mm
2
to 0.5 mm
2
2 conductors with same cross section, flexible 0.08 mm
2
to 0.75 mm
2
Conductor cross section AWG 28 to 16
Stripping length 7 mm
Note
Lose and tighten the screws with a slot screwdriver (2 mm).
Tightening torque: 0.22 N•m to 0.25 N•m.
