18
Ceiling-mount Setup
■ It is recommended that you use the optional
Sharp ceiling-mount adaptor and unit for this
installation. Before mounting the projector,
contact your nearest Sharp Authorized
Projector Dealer or Service Center to obtain
the recommended ceiling-mount adaptor and
unit (sold separately).
Setting up the Projector
Setting up the Projector
For optimal image quality, position the projector perpendicular to the screen with the projector’s feet
flat and level. Doing so will eliminate the need for Keystone correction and provide the best image
quality. (See page 28.)
Standard Setup (Front Projection)
■ Place the projector at the required distance from the screen according
to the desired picture size. (See page 20.)
Example of standard setup
Screen
Lens center
H
L
• Refer to page 20 for additional information concerning “Screen Size and Projection Distance”.
Note
Side View
To Next Page
