RS-232C Specifi cations and Commands
(Continued)
Commands
Example: When turning on the projector, make the following setting.
Computer Projector
POWR___1
o
m
OK
CONTROL CONTENTS COMMAND PARAMETER
RETURN
Power ON
Standby mode
(or 30-second startup time)
Power
On POWR
___
1 OK or ERR OK
Off POWR
___
0 OK OK or ERR
Status POWR????10
Projector Condition
TABN
___
1 0: Normal
1: Temp High
8: Lamp Life 5% or less
16: Lamp Burn-out
32: Lamp Ignition Failure
0: Normal
1: Temp High
2: Fan Error
4: Cover Open
8: Lamp Life 5% or less
16: Lamp Burn-out
32: Lamp Ignition Failure
64:
Temp Abnormally High
Lamp
Status TLPS
___
1 0: Off, 1: On, 2: Retry
3: Waiting, 4: Lamp Error
0: Off, 4: Lamp Error
Power Status TPOW
___
1 1: On, 2: Cooling 0: Standby
Quantity TLPN
___
1 1
Usage Time(Hour) TLTT
___
1 0 – 9999(Integer)
Usage Time(Minute) TLTM
___
1 0, 15, 30, 45
Life(Percentage) TLTL
___
1 0% – 100%(Integer)
Name
Model Name Check TNAM
___
1 PGLX2000/PGLS2000
Model Name Check MNR D
___
1 PG-LX2000/PG-LS2000
Projector Name Setting 1
(First 4 characters) *1
PJN1****OK or ERR
Projector Name Setting 2
(Middle 4 characters) *1
PJN2****OK or ERR
Projector Name Setting 3
(Last 4 characters) *1
PJN3****OK or ERR
Projector Name Check PJN0
___
1 Projector Name
Input Change
COMPUTER I RGB
___
1 OK or ERR ERR
HDMI *2 I RGB
___
2 OK or ERR ERR
VIDEO IVED
___
1 OK or ERR ERR
Input RGB Check IRGB????1: COMPUTER
2: HDMI *2, ERR
ERR
Input Video Check IVED????1: VIDEO, ERR ERR
Input Mode Check IMOD????1: RGB, 2: VIDEO ERR
Input Check ICHK????(XGA) 1: COMPUTER,
2: HDMI, 3: VIDEO
(SVGA) 1: COMPUTER,
2: VIDEO
ERR
Volume
Volume(0 – 60) VOL A
__
**OK or ERR ERR
Volume up/down(-10 – +10) VOUD
_
***OK or ERR ERR
Keystone
-80 – +80
(
XGA
)
/-40 – +40
(
SVGA
)
KEYS****OK or ERR ERR
AV Mute
On IMBK
___
1 OK or ERR ERR
Off IMBK
___
0 OK or ERR ERR
Freeze
On FREZ
___
1 OK or ERR ERR
Off FREZ
___
0 OK or ERR ERR
Auto Sync
Start ADJS
___
1 OK or ERR ERR
Resize COMPUTER
Normal RASR
___
1 OK or ERR ERR
16:9 RASR
___
2 OK or ERR ERR
Native RASR
___
3 OK or ERR ERR
Full RASR
___
5 OK or ERR ERR
Border RASR
___
6 OK or ERR ERR
Area Zoom RASR
__
10OK or ERR ERR
V-Stretch RASR
__
11OK or ERR ERR
HDMI *2
Normal RBSR
___
1 OK or ERR ERR
16:9 RBSR
___
2 OK or ERR ERR
Native RBSR
___
3 OK or ERR ERR
Full RBSR
___
5 OK or ERR ERR
Border RBSR
___
6 OK or ERR ERR
Area Zoom RBSR
__
10OK or ERR ERR
V-Stretch RBSR
__
11OK or ERR ERR
