Sharp NoteVision PG-LS2000 - Dimensions

71
Appendix
Dimensions
Units: inches (mm)
M4 M4
M4
9
21
/32 (245)
12
3
/32 (307)
1
7
/8
(47.6)
3
45
/64 (94)3
25
/64 (86)
5
/8
(15.5)
3
5
/32 (80)
1
1
/4
(31.5)
13
/64
(5)
1
23
/32
(43.5)
5
3
/32 (129) 4
31
/32 (126)
1
61
/64
(49.5)
2
5
/32
(54.5)
4
3
/64 (102.5)
4
1
/16 (103)
Screw hole specs: 75 mm × 104 mm
Depth of mounting holes: 8 mm
Standard screw: M4 (pitch 0.7 mm)
Quantity: 3
•
•
•
•
