PG-LX2000 / PG-LS2000
Specifications
Design and specications subject to change without notice. Brightness values indicate overall average values at the time of shipment and are
stated based on ISO 21118-2005. This international standard replaces the ANSI lumens ratings.
Sharp and related trademarks are trademarks or registered trademarks of Sharp Corporation and/or its afliated entities. DLP, the DLP logo, DLP
Link, DLP medallion and BrilliantColor are trademarks or registered trademarks of Texas Instruments. HDMI is a registered trademark of HDMI
Licensing LLC. Kensington is a U.S. registered trademark of ACCO World Corporation with issued registrations and pending applications on
other countries throughout the world. All other trademarks are the property of their respective owners.
Model Number PG-LX2000 PG-LS2000
Display Device 0.55" DLP® Chip with BrilliantColor™ Technology and 5-Segment Color Wheel
3D Ready Yes – Compatible with DLP® Link™ Technology
Native Resolution / Aspect Ratio XGA (1024 x 768) / 4:3 SVGA (800 x 600) / 4:3
Input Signals Computer RGB UXGA (analog)*1, WSXGA+ (analog)*
1
, SXGA+*
1
, SXGA*
1
, WXGA+ (analog)*
1
,
WXGA*
1
, XGA*
1
(applies to PG-LS2000 only)
, SVGA, VGA, Mac 21", Mac 19", Mac 16", Mac 13"
DTV / HDTV 1080p, 1080i, 1035i, 720p, 576p, 576i, 540p, 480p, 480i; NTSC / PAL / SECAM
Brightness / Contrast Ratio 2800 Lumens / 2000:1
Lens 1.2x Manual Zoom/Focus Lens. F 2.5 – 2.7; f=21.8~25.6mm. Throw ratio: 1:1.9-2.3
Screen Size (Min / Max) 40" – 300" Diagonal
Closed Caption Yes (CC1, CC2)
On-Screen Display Languages Choice of 18 menu selectable on-screen display languages
Horizontal / Vertical Frequency 15 – 110 kHz (H) / 45 – 85 kHz (V)
Fan Noise Eco+Quiet: Off / Eco+Quiet: On 37 dB / 32 dB
Input Terminals HDMI® (PG-LX2000 only), Computer/Component Video (mini D-sub 15-pin), Composite Video (RCA),
Stereo Audio (RCA L/R)
Control and Communications Terminal RS-232C (D-sub 9-pin)
Audio System 2 W (Mono)
Projection Lamp 210 W User Replaceable (replacement part number AN-LX20LP or AN-LX20LP/1) [UPC: 074000374249]
Estimated Lamp Life Eco+Quiet: Off / Eco+Quiet: On Up to 3,000 hours / Up to 5,000 hours
IR Remote Control Functions On, Standby, Magnify (Enlarge), Freeze, Break Timer, AV Mute, Spotlight, Pointer, Adjustment (x4), Effect,
Keystone, Function, Volume Up/Down, Input Select, Picture Mode, Auto Sync, Resize, Menu, Enter, Return,
Eco+Quiet, 3D Mode
Picture Modes Standard, Presentation, sRGB, Movie, Game
Power Source AC 100V – 240V, 50/60 Hz, 2.7 A
Power Consumption Eco+Quiet: Off 100V AC: 267W; 240V AC: 254 W
Eco+Quiet: On 100V AC: 218W; 240V AC: 207 W
Power Consumption Quick Start 100V AC: 1.9 W; 240V AC: 2.3 W
(STANDBY Mode) Eco 100V AC: 0.50 W; 240V AC: 0.85 W
Operating / Storage Temperature +41°F to +95°F (+5°C to +35°C) / -4°F to +140°F (-20°C to +60°C)
Heat Dissipation Eco+Quiet: Off / Eco+Quiet: On 100V AC: 910 BTU per hour / 740 BTU per hour
240V AC: 870 BTU per hour / 710 BTU per hour
Safety Approval UL, FCC Class A
Cabinet Color Dark gray (top cabinet) and light gray (bottom cabinet)
Dimensions (main body only) and Weight (approx.) 12-3/32" (W) x 3-45/64" (H) x 9-21/32" (D); 5.1 lbs.
Carton Dimensions and Weight (approx.) 16-7/32" (W) x 9-1/4" (H) x 13-1/2" (D); 9.9 lbs.
Included Accessories Wireless Remote; two AAA batteries; 6' AC Power Cord; 6' RGB Signal Cable; Initial Setup Guide; CD-ROM
Optional Accessories Replacement Lamp: AN-LX20LP or AN-LX20LP/1; Ceiling Mounting Bracket: AN-XRCM30; Ceiling Mount
Extension Tube (provides 26" to 39" extension): AN-EP101B; Angle Mount Joint (for use with ceiling mount):
AN-JT200; 16" Security Cable System (for use with ceiling mounting bracket): AN-CMCSS16; 46" Security Cable
System (for use with ceiling mounting bracket and extension tube): AN-CMCSS46; 3-RCA (component video) to
15-pin D-sub cable (10’): AN-C3CP2; 3D Active Shutter Glasses: X102; Light Duty Storage Bag: AN-C500SB
UPC 074000374256 074000374263
Limited Warranty *
2
3 Years Parts and Labor including 3 Years of “ER” 24-hour turnaround Express
Repair. 90 day warranty on user-replaceable projection lamp.
*1 Compatible in Intelligent Compression. *2. See warranty statement included with each product or as a PDF download at www.sharpusa.com.
SIICA 12037
