Connecting Peripheral Equipment
6. LAN terminal
• WhenPowerSaveModeisOff,youcanuse“Wakeon
LAN (Magic Packet)” to turn on the power via LAN.
7. TOUCH PANEL terminal 2 (for touch panel)
• Tousethetouchpanelwithacomputer,connectthe
touch panel to the computer with a USB cable.
• Tousethisterminal,connectyourcomputertothevideo
input terminal on the rear of the monitor.
8. RS-232C input terminal
• Youcancontrolthemonitorfromacomputerby
connecting a commercially available RS-232 straight
cable between these terminals and the computer. The
terminal on the monitor is a female-type connector.
9. Audio output terminal
• Theoutputsoundvariesdependingontheinputmode.
• Youcanadjustthevolumefromthespeakersofthis
monitor and the audio output terminal simultaneously by
using VOLUME.
• Whenacableisconnectedtotheaudiooutputterminal,
audio is not output from the monitor speaker.
• Bass,Treble,andBalancecannotbeadjustedonaudio
that is output from the audio output terminal.
10. Audio input terminal
• Useanaudiocablewithoutresistance.
11. D-sub input terminal
12. Digital audio output (optical) terminal
• Audiothatisinputintothemonitorisoutput.
• Connectusingacommerciallyavailableaudiodigital
cable.
• Theoutputsoundvariesdependingontheinputmode.
13. Mini AV input terminal
• ChangetheinputmodetoAV.
• Aconversioncablemustbepurchasedseparately.
Video
Audio (L)
Audio (R)
Video Audio (R)
Audio (L) GND
14. Mini Component input terminal (YPBPR)
• ChangetheinputmodetoYPBPR.
• Aconversioncablemustbepurchasedseparately.
• AsYPBPRterminalshavenoglobalstandards,the
screen display may still be incorrect even if you connect
the cable terminals according to their colors. In that case,
try exchanging the connections so that it will provide a
correct display.
• WhenusingYPBPRinput,pleaseusetheMiniAVinput
terminal as audio input. You cannot use “Audio input
terminal” shown in 10. Please use a terminal with 4-pole
connector pin composed of Video, Audio L, Audio R and
Ground as audio input. Please be aware that your audio
output does not work with 3-pole connector pin composed
of Audio L, Audio R and Ground.
Y
Pb/Cb
Pr/Cr
Y Pr/Cr
Pb/Cb GND
n
How to remove a USB flash drive
1. Start File Explorer. (See page 24.)
2. Touch
of the device you want to unmount.
