Sharp PN-65HC1-LCD - Mounting Precautions (for SHARP Dealers and Service Engineers)

50
E
• Wheninstalling,removingormovingthemonitor,ensurethatthisiscarriedoutbyatleast4people.
• Besuretouseawall-mountbracketdesignedordesignatedformountingthemonitor.
• Thismonitorisdesignedtobeinstalledonaconcretewallorpillar.Reinforcedworkmightbenecessaryforsomematerials
such as plaster / thin plastic board / wood before starting installation.
• Thismonitorandbracketmustbeinstalledonawallwhichcanendureatleast4timesormoretheweightofthemonitor.
Install by the most suitable method for the material and the structure.
• ToattachaVESA-compliantmountingbracket,useM8screwsthatare3/8inch(10mm)to1/2inch(12mm)(PN-65HC1:
9/16 inch (15mm)) longer than the thickness of the mounting bracket.
Screws (M8)
Mounting bracket
Monitor mounting
3/8 - 1/2 inch (10 - 12 mm)
(PN-65HC1: 3/8 - 9/16 inch (10 - 15mm))
• Donotuseanimpactdriver.
• Whenmovingthemonitor,besuretoholdthehandlesorthepartsmarkedby
below. Do not grasp the screen or tray.
This may cause product damage, failure, or injury.
[PN-86HC1] [PN-75HC1] [PN-65HC1]
• Ifyouneedtotemporarilyplacethemonitoronatableorothersurfaceduringinstallation,spreadathicksoftclothonthe
table to prevent damage to the screen and table.
• Priortorepackingorremoval,removethetray.
• Aftermounting,pleasecarefullyensurethemonitorissecure,andnotabletocomeloosefromthewallormount.
• Donotuseanyscrewholesotherthanthoseformountingbrackets,locatedontherearofthemonitor,forinstallation.
Mounting Precautions
(For SHARP dealers and service engineers)
