Menu Items
Adjustments for computer screen display
n
Automatic adjustment
When you use the D-SUB to display a computer screen for the
first time, or when you change the setting of the computer, use
the automatic screen adjustment.
1. Switch the input to D-SUB and display the adjustment
pattern. (See the description below.)
2. Press the MENU button and select “PC Setting” in
“Picture”.
3. Touch “Auto Adjust”.
TIPS
• Ifthescreencannotbeadjustedproperlywithone
automatic adjustment, repeat the automatic adjustment two
or three times. Try manual adjustment if necessary.
n
Screen display for adjustment
Before making adjustments in the Picture menu, display
an image to brighten the entire screen. If you are using
a Windows computer, use the adjustment pattern on the
supplied CD-ROM.
Opening the adjustment pattern
The following example is performed in Windows 10.
1. Load the supplied CD-ROM into the computer’s CD-
ROM drive.
2. Open [CD Drive] in [This PC].
3. Double-click [Adj_uty.exe] in the [Monitor] folder.
The adjustment pattern will appear.
Adjust the screen automatically or manually.
4. When adjustment is finished, press the [Esc] on the
computer’s keyboard to quit the adjustment program.
5. Eject the CD-ROM from the CD-ROM drive.
TIPS
• Ifthedisplaymodeonthecomputeryouareusingis65000
colors, the color levels in the color pattern may appear
differently or grayscale may appear to be colored. (This
is due to the specifications of the input signal and is not a
malfunction.)
