Part Names
n
Remote control unit
(Supplied with the PN-ZR02 (optional))
1
2
1. Signal transmitter
2. Operation buttons (See page 22.)
24. HDMI input terminal (See page 12.)
25. Vents
26. AC input terminal (See page 15.)
27. Main power switch (See page 16.)
28. USB Type C output terminal (See page 13.)
29. USB port for storage expansion (USB 3.0 compliant) (See page 13.)
30. LAN 2 terminal (See page 13.)
31. Line out Audio output terminal (See page 12.)
32. LAN 1 terminal (See page 13.)
33. USB port for IoT sensor hub/USB devices (See page 12.)
34. USB port for IoT sensor hub/USB devices (See page 12.)
35. Mounting points for IoT sensor hub (See page 14.)
36. Mounting points for camera (See page 14.)
