14
E
Connecting the Power Cord
Caution
• Use only the power cord supplied with the monitor.
1. Turn off the main power switch.
2. Plug the power cord (supplied) into the AC input terminal.
3. Plug the power cord (supplied) into the power outlet.
Main power switch
PN-LC652
11
Main power switch
Power cord (Supplied)
terminal
For power outlet
TIPS
• Be sure to clamp the power cord (supplied) by using the supplied cable clamp. When clamping the power cord, take care not
to stress the terminal of the power cord. Do not bend the power cord excessively.
Cable clamp (Supplied)
Power cord (Supplied)
Binding Cables
The supplied cable clamps can be used to clamp the power cord and cables connected to the back of the monitor.
Attach the supplied cable clamps to a flat surface, removing any dust or dirt before attaching.
Do not attach over a vent.
Cable clamp
Affixing point
Cable
To Next Page
