PICTURE menu
Function Command Direction Parameter Reply Control/Response contents *
BRIGHT VLMP WR 0-31 0-31
○
CONTRAST CONT WR 0-60 0-60
BLACK LEVEL BLVL WR 0-60 0-60
TINT TINT WR 0-60 0-60
COLORS COLR WR 0-60 0-60
SHARPNESS SHRP WR 0-24 0-24
COLOR
ADJUSTMENT
COLOR MODE BMOD WR 0 0 STD
2 2 VIVID
3 3 sRGB (sRGB cannot be used when input mode is D-SUB[COMPONENT].)
4 4 HIGH ILLUMINANCE
WHITE BALANCE WHBL WR 0-3 0-3 0:THRU, 1:PRESET, 2:USER, 3:ADJUST UNIFORMITY
PRESET CTMP WR 1-28 1-28
From 1: approximately 3,000K to 15: approximately 10,000K (500K steps)
16: approximately 5,600K, 17: approximately 9,300K, 18: approximately 3,200K
From 19: approximately 10,500K to 28: approximately 15,000K (500K steps)
“ERR” when WHBL is not set to 1.
USER R-CONTRAST CRTR WR 0-256 0-256 “ERR” when WHBL is not set to 2.
G-CONTRAST CRTG WR 0-256 0-256
B-CONTRAST CRTB WR 0-256 0-256
R-OFFSET OFSR WR -127-127 -127-127
G-OFFSET OFSG WR -127-127 -127-127
B-OFFSET OFSB WR -127-127 -127-127
ADJUST
UNIFORMITY
R-CONTRAST CRTR WR 0-256 0-256 “ERR” when WHBL is not set to 3.
G-CONTRAST CRTG WR 0-256 0-256
B-CONTRAST CRTB WR 0-256 0-256
R-OFFSET OFSR WR -127-127 -127-127
G-OFFSET OFSG WR -127-127 -127-127
B-OFFSET OFSB WR -127-127 -127-127
BRIGHTNESS
VALUE
BCLB WR 0-255 0-255
COPY TO USER CPTU W 0 Copies a preset value to the user setting.
GAMMA GAMM WR 0-9 0-9
0: 1.8, 1: 2.2, 2: 2.4, 3: DICOM SIMULATION, 4:USER, 5:2.0, 6:STD, 7:LIGHT 2,
8:LIGHT 1, 9:DARK
FLESH TONE FLES WR 0-2 0-2 0: OFF, 1: LOW, 2: HIGH
C.M.S.-HUE
CMHR WR -10-10 -10-10 R
CMHY Y
CMHG G
CMHC C
CMHB B
CMHM M
CRST W 1 Resets the hue.
C.M.S.-SATURATION
CMSR WR -10-10 -10-10 R
CMSY Y
CMSG G
CMSC C
CMSB B
CMSM M
CRST W 2 Resets the saturation.
Controlling the Monitor with a computer (RS-232C)
