Supplied Components
If any components are missing, please contact your dealer.
Liquid Crystal Display Monitor: 1
Cable clamp: 4
Cable clamp (insertion type): 2
Power cord
CD-ROM (Utility Disk for Windows): 1
Setup Manual: 1
Remote control sensor box mounting hole concealing sticker: 2
* The remote control unit is supplied with the PN-ZR02 control kit (optional).
* SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission.
* For environmental protection!
Do not dispose of batteries in household waste. Follow the disposal instructions for your area.
Contents
IMPORTANT INFORMATION ............................................3
DEAR SHARP CUSTOMER ..............................................4
SAFETY PRECAUTIONS ..................................................4
TIPS AND SAFETY INSTRUCTIONS ...............................6
MOUNTING PRECAUTIONS ............................................7
Supplied Components ..................................................... 8
Part Names .......................................................................9
Connecting Peripheral Equipment ............................... 11
Multiple monitor connection .......................................13
Connecting the Power Cord .........................................15
Binding Cables ............................................................... 16
Preparing the Remote Control Unit .............................. 17
Installing the batteries ................................................17
Remote control operation range .................................17
Turning Power On/Off .................................................... 18
Turning on the main power.........................................18
Turning power on/off ..................................................18
Disabling power on/off operations ..............................19
Basic Operation .............................................................20
Remote Control Mode ..................................................23
Menu Items .....................................................................24
Displaying the menu screen ....................................... 24
Menu item details .......................................................25
Adjustments for computer screen display ..................36
Initialization (Reset)/Functional Restriction Setting
(FUNCTION) ....................................................................37
Controlling the Monitor with a computer (RS-232C)
...38
Computer connection .................................................38
Communication conditions .........................................38
Communication procedure .........................................38
Setting of the GAMMA user data ................................ 41
RS-232C command table ........................................... 42
Controlling the Monitor with a computer (LAN) .......... 51
Settings to connect to a LAN ......................................51
Controlling with a computer ........................................53
[Advanced operation]
Command-based control ............................................ 60
Troubleshooting .............................................................61
Specications ...............................................................63
Mounting Precautions
(For SHARP dealers and service engineers) ............... 69
