Sharp PS-940 User Manual

EN
What is included in the box
1 x PS-940
1 x EU Power Cord
1 x UK Power Cord
1 x Microphone
1 x User Manual
1 x Quick start guide
1 x Warranty Card
Panels & Controls
TOP VIEW
1. 6.3mm MIC JACK
2. 6.3mm GUITAR JACK
3. 3.5mm AUX IN JACK
4. AUDIO-1(BT/USB/AUX MODE)
5. BLUETOOTH CONNECTION BUTTON
6. A-VOLUME KNOB
7.
STANDBY BUTTON
8.
PREVIOUS BUTTON
9. POWER INDICATOR
10. EQ SLIDER-A / EQ SLIDER-B
11. USB PORT FOR PLAYBACK
12. USB PORT FOR CHARGE
13. AUDIO-2 (MIC/GUITAR/AUX MODE)
14. LIGHT BUTTON
15. SUPER BASS BUTTON
16. B-VOLUME KNOB
17.
PLAY/PAUSE BUTTON
18.
NEXT BUTTON
19. CHARGE INDICATOR
20. DISPLAY SCREEN
BACK VIEW
1. HANDLE
2. MIC HOLDER
3. POWER SOCKET
4. POWER SWITCH
OPERATION INSTRUCTION
BASIC FUNCTIONS
POWER ON/OFF YOUR UNIT
Select an appropriate power cord and plug it into the POWER SOCKET.
Switch the POWER SWITCH to ON. The speaker will turn to Standby mode
automatically, and the POWER INDICATOR will be lit up in red color.
TURNING THE UNIT ON/OFF
Press the STANDBY button to turn ON or OFF the unit.
SETTING THE PLAYBACK MODE
To change the playback modes, rotate the AUDIO-1 KNOB to choose: BT,
AUX, USB, OFF.
SETTING THE INPUT MODE
Rotate the AUDIO-2 KNOB to choose: MIC/GUITAR, AUX.
ADJUST THE VOLUME
1. Rotate the A-VOLUME KNOB to increase or decrease the music volume.
2. Rotate the B-VOLUME KNOB to adjust the microphone, guitar volume.
3. When AUDIO-1 and AUDIO-2 are both set to AUX, the volume can be
adjusted by A-VOLUME and B-VOLUME.
EQUALIZER (EQ) ADJUSTMENT
Use the EQ SLIDER A and B to adjust an e ect that best matches the music
style: ROCK,
JAZZ, FLAT, SAMBA, POP.
1. EQ SLIDER A is to adjust the sound e ect for Audio-1(BT/AUX/USB).
2. EQ SLIDER B is to adjust the sound e ect for Audio-2(MIC/GUITAR).
SUPER BASS ADJUSTMENT
Press the SUPER BASS button to increase the bass e ect. Once the SUPER
BASS is activated, the  ashing light will be turned on, and the decoration
LED lighting around the speakers will  ash in blue.
NOTES: The EQ SLIDER A/B cannot work once the SUPER BASS is activated.

Sharp PS-940 Specifications

General

Type	Freestanding Public Address (PA) system
Light effects	Yes
Product color	Black
Suitable for outdoor use	-
Number of tweeter drivers	2
AUX in ports	1
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
AC input voltage	220 - 240 V
Power source type	AC, Battery
AC input frequency	50 Hz
Battery life (max)	14 h
Frequency range	- Hz
RMS rated power	180 W
Audio formats supported	FLAC, MP3, WAV
Cables included	AC
Quantity per pack	1 pc(s)
Equalizer bands quantity	5
Master (outer) case width	285 mm
Master (outer) case height	708 mm
Master (outer) case length	365 mm
Master (outer) case weight	10100 g

Weight and Dimensions

Depth	300 mm
Width	224 mm
Height	635 mm
Weight	8000 g
Woofer diameter (imperial)	6.5 \
Tweeter diameter (imperial)	2 \
