Sharp R-202 User Manual

2
OVEN AND ACCESSORIES
1
2
3
4567
8
10
9
11
12
13
ACCESSORIES:
Check to make sure the following accessories
are provided:
(11) Turntable (12) Roller stay (13) Seal Packing
Place the roller stay in the seal packing on the floor
of the cavity.
Then place the turntable on to the roller stay.
To avoid damage to the turntable, when removing
dishes/containers from the microwave oven, please
ensure that you lift them clear of the turntable rim.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
1 Control panel
2 Oven lamp
3 Door opening handle
4 Waveguide cover
5 Seal Packing
6 Oven cavity
7 Door seals and sealing surfaces
8 Ventilation openings
9 Outer cabinet
10 Power cord

Sharp R-202 Specifications

Power

AC line voltage	230V, 50Hz, single phase
AC power required	1.24KW
output power	800W(IEC 705)
microwave frequency	2450MHz
oven lamp	25W/240-250V

Capacity

oven capacity	20 litres

Weight and Dimensions

outside dimensions	449mm(W) x 282mm(H) x 385mm(D)
cavity dimensions	287mm(W) x 220mm(H) x 311mm(D)
turntable diameter	ø272mm
weight	Approx. 13.3kg
