Sharp R-203EW - Replacement Parts List; Electric, Cabinet, and Control Panel Parts; Oven, Door, and Miscellaneous Parts

29
R-202EW
R-203EW
*
*
*
*
∆
*
∆
*
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
ELECTRIC PARTS
1- 1 QSW-MA137WRE0 Second interlock switch/ Door sensing switch 2 AH
1- 1 QSW-MA085WRE0
Second interlock switch/ Door sensing switch (Interchangeable) 2AF
1- 2 FFS-BA027WRKZ
C/T fuse (120˚C, 13A) and monitor switch assembly (AM51620C53Y1) 1AS
1- 3 FACCDA079WRE0 Power supply cord 1 AF
1- 3 FACCDA064WRE0 Power supply cord (Interchangeable) 1 AF
1- 4 FH-DZA102WRKZ High voltage rectifier assy 1 AN
1- 4 FH-DZA088WRK0 High voltage rectifier assy (Interchangeable) 1 AP
1- 5 RC-QZA307WRZZ High voltage capacitor 1 AX
1- 5 RC-PZA041WRE0 High voltage capacitor (Interchangeable) 1 AS
1- 6 RMOTEA383WRE0 Fan motor 1 AV
1- 6 RMOTEA355WRE0 Fan motor (Interchangeable) 1 AU
1- 7 RV-MZA226WRE0 Magnetron 1 BE
1- 7 RV-MZA306WRZZ Magnetron (Interchangeable) 1 BL
1- 8 RLMPTA082WRZZ Oven lamp 1 AL
1- 9 RMOTDA186WRE0 Turntable motor 1 AW
1- 9 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1- 9 RMOTDA229WRE0 Turntable motor (Interchangeable) 1 AQ
1-10 QFS-TA038WRE0 Temperature fuse 120˚C (Oven) 1 AK
1-11 RTRN-A648WRZZ Power transformer 1 BH
CABINET PARTS
2- 1 GCABUA817WRPZ Outer case cabinet 1 BD
2- 2 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 FPNLCB571WRKZ Control panel frame with key unit 1 BC
3- 1-1 FUNTKB067WREZ Key unit 1 AY
3- 2 JBTN-B151WRFZ Open button 1 AF
3- 3 MSPRCA050WRE0 Open button spring 1 AB
3- 4 DPWBFC188WRUZ Control unit 1 BH
3- 5 QCNC-A014WRZZ Rubber connector 1 AE
3- 6 RLCDSA097DRZZ Liquid crystal display 1 AM
3- 7 XEPSD30P08XS0 Screw; 3mm x 8mm 3 AA
OVENPARTS
4- 1 PHOK-A120WRFZ Latch hook 1 AH
4- 2 LBNDKA038WRP0 Capacitor holder 1 AF
4- 3 NFANJA029WRE0 Fan blade 1 AK
4- 4 PDUC-A777WRPZ Fan duct 1 AP
4- 5 ************* Oven cavity (Not replaceable part) 1--
4- 6 GCOVHA425WRPZ Turntable motor cover 1 AK
4- 7 MLEVPA241WRFZ Switch lever 1 AG
4- 8 PCOVPA276WRE0 Waveguide cover 1 AM
4- 9 PCUSUA237WRP0 Cushion 2 AF
4-10 PPACGA176WREZ TTM packing 1 AC
DOORPARTS
5- 1 FDORFA348WRTZ Door panel assembly 1 BC
5- 2 GWAKPA809WRRZ Door frame 1 AR
5- 3 HPNL-A764WREZ Door screen 1 AP
5- 4 LSTPPA205WRFZ Latch head 1 AF
5- 5 MSPRTA187WRE0 Spring 1 AC
5- 6 PSHEPA782WREZ Sealer film 1 AG
5- 7 GCOVHA424WRFZ Choke cover 1 AK
MISCELLANEOUS
6- 1 NTNT-A034WRF0 Turntable [R-202EW] 1 AM
6- 1 NTNT-A060WRE0 Turntable [R-203EW] 1 AP
6- 2 FROLPA099WRKZ Turntable support 1 AP
6- 3 TCAUAA258WRRZ Monitor caution 1 AC
6- 4 TCAUAA268WRRZ DHHS caution label 1 AF
6- 5 TINSEA893WRRZ Instruction book 1 AM
6- 6 FW-VZB837WREZ Main wire harness 1 AR
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 screw : 4 mm x 8 mm 2 AC
