Sharp R-24AT Service Manual

R-22AT
R-24AT
30
SERVICE INFORMATION
IMPORTANT: When the magnetron MG1 and/or MG2 is replacing, the relays (RY3 and RY4) on control unit must
be replaced at the same time. Because if the magnetron's life has been over, the relay's life may
also be over.
UPPER AND LOWER LATCH HEADS REMOVAL
7. Remove the door release lever from the door assem-
bly.
8. Remove the three (3) screws holding the joint plate to
the door panel.
9. Release the latch spring from the tab of the joint lever
and joint plate.
10.Release the latch heads from joint lever and joint plate.
11.Now, the latch heads are free.
DOOR CASE REMOVAL
1. Remove the door assembly from oven cavity, referring
to "REMOVAL" of "DOOR REPLACEMENT AND AD-
JUSTMENT".
2. Remove choke cover from door panel, referring to
"CHOKE COVER REMOVAL".
3. Remove door handle from door panel, referring to
"DOOR HANDLE REMOVAL".
4. Bend up four (4) nails of door case.
5. Remove door case from door panel.
6. Now, the door case is free.
DOOR GLASS REMOVAL
7. Remove the four (4) screws holding two (2) outside
window fixing plates to door panel.
8. Now, the door glass is free.

Sharp R-24AT Specifications

General

Turntable	-
Clock type	Electronic
Door hinge	Left
Control type	Buttons
Product color	Stainless steel
Door open type	Pull-out
Microwave power	1900 W
Built-in display	Yes
Appliance placement	Countertop
Number of power levels	11
Auto programs quantity	10
Current	13 A
Connected load	2900 W
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	470 mm
Width	510 mm
Height	335 mm
Weight	33000 g
Interior dimensions (W x D x H)	330 x 330 x 180 mm
