R-25AM
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
∆
*
∆
*
*
*
ELECTORIC PARTS
BM FMOTEA482WRKZ Blower motor 1 BH
C1, C2 RC-QZA320WRZZ High voltage capacitor 2 AV
F1,F2 QFS-CA026WRZZ Fuse F10A 2 AH
F3 QFS-CA017WRE0 Weak point A017 1 AF
F4,F5 QFS-IA002WRE0 High voltage fuse 0.75A/ 5kV 2 AQ
MG1 RV-MZA322WREZ Magnetron (Upper) 1 BB
MG2 RV-MZA322WREZ Magnetron (Lower) 1 BB
OL RLMPTA028WRE0 Oven lamp 1 AK
SM RMOTDA238WRZZ Antenna motor 2 AR
SW1 QSW-MA085WRE0 Interlock switch 1 AF
SW2 QSW-MA085WRE0 Interlock switch 1 AF
SW3 QSW-MA086WRE0 Monitor switch 1 AF
SW4 QSW-MA086WRE0 Monitor switch 1 AF
SW5 QSW-MA085WRE0 Stop switch 1 AF
T1, T2 RTRN-A599WRE0 High voltage transformer 2 BM
T3 RTRNPA005WRZZ Touch control transformer 1 AQ
TF1 QFS-TA014WRE0 Temperature fuse 150C (Upper magnetron) 1 AG
TF2 QFS-TA014WRE0 Temperature fuse 150C (Lower magnetron) 1 AG
TF3 QFS-TA015WRE0 Temperature fuse 120C (Exhaust) 1 AG
TH1 FH-HZA070WRE0 Magnetron thermistor (Upper) 1 AM
TH2 FH-HZA070WRE0 Magnetron thermistor (Lower) 1 AM
TH3 FH-HZA070WRE0 Exhaust thermistor 1 AM
1- 1 FACCVA013WRK0 Power supply cord 1 BG
1- 2 QSOCLA024WRE0 Oven lamp socket 1 AH
1- 3 FW-QZA117WRK0 High voltage rectifier assembly 1 AU
1- 4 FPWBFA335WRE0 Noise filter 1 AX
1- 5 QFSHDA019WRE0 Fuse holder 2 AH
CABINET PARTS
2- 1 GDAI-A353WRTZ Base plate 1 BB
2- 2 GCABUA860WRPZ Outer case cabinet 1 BD
2- 3 GCOVAA283WRW0 Rear cabinet 1 AX
2- 4 FFTASA064WRY0 Oven lamp access cover assembly 1 AN
2- 4-1 PCUSUA585WRPZ Cushion 1 AF
2- 4-2 PREFHA059WRP0 Reflector 1 AF
2- 5 FFPF-A016WRK0 Vibration-proof sheet 1 AU
2- 6 PSHEGA007WRE0 Rubber sheet B 2 AE
CONTROL PANEL PARTS
3- 1 DPWBFC366WRKZ Control unit 1 BN
3- 1A QCNCMA314DRE0 5-pin connector (CN-A) 1 AC
3- 1B QCNCMA413DRE0 6-pin connector (CN-B) 1 AC
3- 1C QCNCMA420DRE0 5-pin connector (CN-C) 1 AK
3- 1D QCNCMA493DRZZ 6-pin connector (CN-D) 1 AE
3- 1E QCNCMA381DRE0 5-pin connector (CN-G) 1 AD
3- 1F RV-KXA053DRE0 Fluorescent display tube 1 AW
3- 1G PCUSGA359WRP0 Cushion 2 AC
3- 1H QCNCMA338DRE0 3-pin connector (CN-E) 1 AB
BZ RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
C1 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C2 VCEAG51HW228M Capacitor 2200uF 50V 1 AH
C3 VCEAG31HW106M Capacitor 10uF 50V 1 AB
C4 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C5 VCEAG31HW106M Capacitor 10uF 50V 1 AB
C6-7 VCKYD11CY103N Capacitor 0.01uF 16V 2 AA
C8 VCEAG31CW107M Capacitor 100uF 16V 1 AC
C9 VCEAG31HW106M Capacitor 10uF 50V 1 AB
C10 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C21 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C22 VCKYD11CY103N Capacitor 0.01uF 16V 1 AA
C30 VCKYD11CY103N Capacitor 0.01uF 16V 1 AA
C31 VCEAG31HW106M Capacitor 10uF 50V 1 AB
C60 VCKYD11CY103N Capacitor 0.01uF 16V 1 AA
C62-63 VCKYD11CY103N Capacitor 0.01uF 16V 2 AA
C70 VCKYD11CY103N Capacitor 0.01uF 16V 1 AA
C74 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C75-76 VCKYD11CY103N Capacitor 0.01uF 16V 2 AA
C80 VCKYD11HF104Z Capacitor 0.1uF 50V 1 AB
C81 VCEAG31HW106M Capacitor 10uF 50V 1 AB
C98-100 VCKYD11HB331K Capacitor 330pF 50V 3 AA
CF1 RCRS-A010DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-7 VHD10EDB10+-1T Diode (10EDB10) 7 AB
D70 VHD10EDB10+-1T Diode (10EDB10) 1 AB
