Sharp R-25AM Service Manual

40
R-25AM
REF. NO. PART NO. DESCRIPTION Q'TY CODE
D71 VHD1SS133//-2 Diode (1SS133) 1 AA
D81 VHD1SS133//-2 Diode (1SS133) 1 AA
D83-84 VHD1SS133//-2 Diode (1SS133) 2 AA
F1 QFS-IA001KKZZ Fuse 2.5A 50V 1 AD
I- 1 RH-IXA222DRZZ LSI 1 AU
I- 2 VHICAT24W16-1 EEPROM 1 AF
Q2 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q3 VHIKIA79L05-3 Transistor (KIA79L05P) 1 AE
Q11 VS2SB953-PQ-4 Transistor (2SB953) 1 AG
Q20 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q40 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q41 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q80 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q81 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q86-87 VSDTB143ES/-3 Transistor (DTB143) 2 AC
R1 VRD-B12EF152J Resistor 1.5k ohm 1/4W 1 AA
R2 VRS-B13AA271J Resistor 270 ohm 1W 1 AA
R3 VRS-B13AA151J Resistor 150 ohm 1W 1 AA
R5 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R21 VRD-B12EF563J Resistor 56k ohm 1/4W 1 AA
R22 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R30 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R31 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R40 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R41 VRD-B12EF203J Resistor 20k ohm 1/4W 1 AA
R42 VRD-B12EF393J Resistor 39k ohm 1/4W 1 AA
R43 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R60 VRD-B12EF333J Resistor 33k ohm 1/4W 1 AA
R62-63 VRD-B12EF112J Resistor 1.1k ohm 1/4W 2 AA
R64-65 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R67 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R70 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R71 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R73-74 VRD-B12EF104J Resistor 100k ohm 1/4W 2 AA
R75-76 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R93-97 VRD-B12EF472J Resistor 4.7k ohm 1/4W 5 AA
RY1 RRLY-B004MRE0 Relay (FTR-F3AA024E) 1 AF
RY3-4 RRLY-A113DRE0 Relay (DU24D1-1PR(M)) 2 AM
VRS1 VHV10V471K+-1 Varistor (TNR10V471K) 1 AD
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
ZD2 VHEHZ4C3///-1 Zener diode (HZ4C3) 1 AA
3- 2 FPNLCB775WRKZ Control panel frame with key unit assembly 1 BB
3- 2-1 GMADIA067WRF0 Display window 1 AE
3- 2-2 HDECAA245WRPZ Decoration metal fittings 1 AU
3- 2-3 HPNLCB838WRFZ Control panel 1 AN
3- 2-4 PCUSUA417WRP0 Cushion 1 AB
3- 3 LANGTA243WRW0 Control panel mounting angle 1 AF
3- 4 XEPSD30P10XS0 Screw : 3mm x 10mm 11 AA
3- 5 XEPSD40P12000 Screw : 4mm x 12mm 2 AA
3- 6 PCUSGA638WRPZ Cushion 2
3- 7 JKNBKA510WRM0 Knob 1 AE
3- 8 DPWBFC373WRKZ Rotary encoder unit 1 AG
3-8-1 RVR-BA018WRE0 Rotary encoder 1
3-8-2 FW-VZA289DRZZ Lead wire harness (3-pin) 1 AE
3- 9 LANGTA304WRP0 Rotary encoder mounting plate 1 AD
3- 10 JBTN-A895WRM0 Select button 4 AE
3- 11 JBTN-A896WRM0 Start button 1 AE
3- 12 DPWBFC372WRKZ Switch unit assembly 1 AH
3- 12-1 FW-VZA165DRE0 Lead wire harness (2-pin) 1 AF
3- 12-2 FW-VZA287DRZZ Lead wire harness (5-pin) 1 AF
3- 12-3 QSW-PA025DRE0 Tact switch (SW1-SW5) 5 AD
3- 13 PCUSUA404WRP0 Select cushion 4 AC
3- 14 PZETEA088WRPZ Insulater 1 AH
3- 15 MSPRPA082WRE0 Spring 1 AD
3- 16 XHTSD40P08RV0 Screw : 4mm x 8mm 1 AA
3- 17 PSHEGA005WRP0 Water proof sheet 1 AE
3- 18 LX-NZ0068WRE0 Special nut 1 AA
OVEN PARTS
4- 1 PCLICA042WREZ Chassis clip 4 AC
4- 2 FDUC-A345WRY0 Exhaust duct assembly 1 AP
4- 3 FOVN-A444WRY0 Oven cavity 1 BS
4- 4 PFILWA053WRP0 Oven light screen (Inside) 1 AE
4- 5 MLEVPA153WRF0 Switch lever A 1 AC
4- 6 MLEVPA154WRF0 Switch lever B 1 AC
∆
