Sharp R-25AM Service Manual

41
R-25AM
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
4- 7 MLEVPA155WRF0 Switch lever C 1 AC
4- 8 MSPRCA075WRE0 Switch spring A 1 AB
4- 9 MSPRCA076WRE0 Switch spring B 2 AB
4-10 PHOK-A081WRF0 Latch hook 1 AP
4-11 MHNG-A216WRM0 Lower oven hinge 1 AG
4-12 PCUSUA626WREZ Cushion 1 AC
4-13 PCUSU0407WRP0 Cushion 2 AA
4-14 FGLSPA063WRY0 Ceramic shelf 1 BF
4-15 FPLT-A008WRY0 Stirrer antenna upper assembly 1 AV
4-16 FPLT-A009WRY0 Stirrer antenna lower assembly 1 AV
4-17 PCUSUA538WRPZ Cushion 1 AD
4-18 LANGQA370WRP0 Oven lamp mounting plate 1 AD
4-19 LBNDKA068WRP0 Capacitor holder 1 AD
4-20 PGIDHA054WRW0 Water-proof cover 1 AF
4-21 NSFTPA031WRF0 Antenna motor shaft 2 AH
4-22 PZETEA087WRPZ Insulater 1 AE
4-23 PCUSUA417WRP0 Cushion 1 AB
4-24 MHNG-A215WRM0 Upper oven hinge 1 AG
4-25 PCUSUA413WRP0 Cushion 1 AG
4-26 PCUSUA415WRP0 Cushion 1 AC
4-27 PDUC-A729WRF0 Air duct 1 AL
4-28 PDUC-A564WRW0 Mg exhaust duct 1 AP
4-29 PCUSUA414WRP0 Cushion 1 AD
4-30 LANGKA679WRPZ Fixing angle S 1 AD
4-31 HDECQA147WRM0 Corner cap right 1 AE
4-32 LANGFA195WRW0 Chassis support 1 AH
4-33 LBSHCA012WRE0 Cord bushing 1 AD
4-34 FCOVPA032WRKZ Stirrer cover assembly 1 BF
4-35 FFIL-A005WRK0 Air intake filter assembly 1 AS
4-36 HDECEA001WRP0 Decoration sash 1 AR
4-37 HDECQA146WRM0 Corner cap left 1 AE
4-38 PCUSGA409WRP0 Cushion 2 AE
4-39 LANGQA440WRM0 Earth angle 1 AE
4-40 LANGQA512WRP0 Thermistor angle 2 AE
4-41 LANGQA593WRPZ Blower motor angle 1 AH
4-42 MSPRCA101WRE0 Switch lever spring C 1 AC
4-43 PCUSUA268WRP0 Cushion 1 AA
DOOR PARTS
5 DDORFA850WRK0 Door assembly 1 BV
5- 1 FDORFA289WRT0 Door panel assembly 1 BH
5- 2 GCOVAA242WRY0 Door case 1 BD
5- 3 FHNDMA011WRY0 Door lever assembly 1 AP
5- 4 GCOVHA350WRF0 Choke cover 1 AR
5- 5 JHNDMA039WRM0 Door handle 1 AX
5- 6 LANGKA766WRP0 Outside window fixing plate 2 AF
5- 7 PCUSGA430WRP0 Cushion 2 AM
5- 8 PGLSPA457WRE0 Door glass 1 AV
5- 9 PPACGA142WRP0 Door case packing 2 AF
5-10 PSHEPA428WRE0 Sealer film 1 AF
5-11 PGID-0024WRF0 Handle guide 4 AC
5-12 XFPSD40P08K00 Screw : 4mm x 8mm 3 AA
5-13 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
5-14 FANGKA200WRY0 Latch fixing angle 1 AQ
5-15 FLEVFA019WRY0 Joint lever 1 AP
5-16 LSTPCA002WRM0 Latch head 2 AM
5-17 MLEVPA220WRF0 Head lever 1 AM
5-18 MSPRCA097WRE0 Latch spring 1 AG
5-19 HBDGCA114WREZ Door badge 1 AK
5-20 PGID-0025WRF0 Handel spacer 1 AC
5-21 PCUSGA486WRP0 Cushion 1 AM
5-22 PSPA-A102WRE0 Door case spacer 2 AE
5-23 XBPSD40P10K00 Screw : 4mm x 10mm 2 AA
MISCELLANEOUS
6- 1 TINSMA019WRRZ Operation manual 1 AH
6- 2 LHLDWQ005YBE0 Purse lock LL 1 AA
6- 3 FW-VZB999WREZ Switch harness 1 AP
6- 4 FW-VZC001WREZ Main wire harness 1 BC
6- 5 LHLDWA040WRE0 Wire holder A 1 AB
6- 6 LBNDKA079WRE0 Wire holder 2 AB
6- 7 TCAUHA168WRR0 H caution label 1 AH
6- 8 TCAUHA257WRR0 S caution sheet 1 AE
6- 9 PZET-A018WRE0 Terminal insulator 2 AC
6-10 TLABSA064WRR0 A017 label 1 AC
6-11 TLABSA055WRR0 Fuse label F10A 2 AE
∆
∆
∆
