R308KW
4 – 1
R308KW
Service Manual
CHAPTER 4. PRODUCT DESCRIPTION
[1] SPECIFICATIONS
ITEM DESCRIPTION
Power Requirements
120 Volts
60 Hertz
Single phase, 3 wire grounded
Power Consumption 1530W / Approx. 13 Amperes
Power Output
1100 W nominal of RF microwave energy (IEC Test procedure)
Operating frequency 2450 MHz
Case Dimensions
Width 20-1/2" (520mm)
Height 12-1/4" (310mm)
Depth 17-3/8" (441mm)
Cooking Cavity Dimensions
(1.0 Cubic feet)
Width 14-3/4" (375mm)
Height 8-1/8" (206mm)
Depth 15-1/4" (387mm)
NOTE: Internal capacity is calculated by measuring
maximum width, depth and height.
Actual capacity for holding food is less.
Control Complement
Touch Control System
Clock (1:00 - 12:59)
Timer (0 - 99 minutes 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI -------------------- Full power throughout the cooking time
P-90 -------------------- approx. 90% of FULL Power
P-80 -------------------- approx. 80% of FULL Power
P-70 -------------------- approx. 70% of FULL Power
P-60 -------------------- approx. 60% of FULL Power
P-50 -------------------- approx. 50% of FULL Power
P-40 -------------------- approx. 30% of FULL Power
P-30 -------------------- approx. 40% of FULL Power
P-20 -------------------- approx. 20% of FULL Power
P-10 -------------------- approx. 10% of FULL Power
P-0 ---------------------- No power throughout the cooking time
POPCORN pad
MINUTE PLUS pad
SHORT CUTS pads
REHEAT pad
COOK pad
DEFROST pad
Number selection pads
POWER LEVELK pad
TIMER / CLOCL pad
STOP/CLEAR pad
START pad
Oven Cavity Light Yes
Safety Standard
UL Listed.
FCC Authorized
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J
