R343M - 3
WARNING
Servicing and repair work must be carried out only by
trained service engineers.
The parts marked '*' on the parts list and schematic
diagram have voltages in excess of 250V.
Removal of the outer wrap gives access to potential
above 250V.
All the parts marked "∆" on the parts list may cause undue
microwave exposure, by themselves, or when they are
damaged, loosened or removed.
CAUTION
MICROWAVE RADIATION
Do not become exposed to radiation from the
magnetron or other parts conducting microwave
energy. All input and output microwave
connections, waveguides, flanges and gaskets must
be secured. Never operate the device without a
microwave energy absorbing load attached. Never
look into an open waveguide or antenna while the
device is energized.
WARNING
THIS APPLIANCE MUST BE EARTHED. THE WIRES IN THIS MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH BLUE : NEUTRAL BROWN : LIVE
If the mains lead is replaced, only part number QACCBA032WRE3 should be used
SPECIFICATION
Power Requirements 230 -240 Volts 50 Hertz Single phase, 3 wire earthed
Power Consumption 1.45kW
Power Output 900 watts nominal of RF microwave energy
Operating frequency of 2450 MHz
Case Dimensions Width 520 mm Height 305 mm including foot Depth 413 mm
Cooking Cavity Dimensions Width 342 mm Height 207 mm Depth 368 mm
Turntable diameter 325 mm
Control Complement Simple Touch Control System
Clock (1.00 - 12.59 or 0.00 - 23.59)
Microwave Power for Variable Cooking
Repetition Rate:
HIGH Full power throughout the cooking time
MEDIUM HIGH approx. 70% of FULL Power
MEDIUM approx. 50% of FULL Power
MEDIUM LOW approx. 30% of FULL Power
LOW approx. 10% of FULL Power
START/AUTO MINUTE pad AUTO COOK/DEFROST pad
POWER LEVEL/WEIGHT pad MORE/LESS pads
STOP/CLEAR pad
Time pads
Set Weight Approx. 17 kg
PRODUCT DESCRIPTION
CAUTION / WARNING
As part of our policy of continuous improvement, we reserve the
right to alter design and specifications without notice
