Sharp R-343WM - Part List

R343M - 17
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§' 'mark : Spare part delivery section.
PART LIST
*
*
*
*
*
*
*
*
∆
∆
∆
∆
CABINET PARTS
∆
∆
CONTROL PANEL PARTS
REF NO PART NO § DESCRIPTION Q'TY CODE
3- 1 DPWBFB852WRK0 U Control unit 1 BL
3- 1A QCNCMA430DRE0 U 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA414DRE0 U 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA218DRE0 U 4P harness (WH-1) 1 AE
3- 1D RLCDSA036DRE0 U Liquid crystal display 1 AP
3- 1E LHLD-A179WRF0 U LED holder 1 AE
3- 1F PSHEPA601WRE0 U LED sheet 1 AD
C1 VCEAB31VW227M U Capacitor 220 uF 16V 1 AB
C10 RC-KZA087DRE0 U Capacitor 0.01 uF 16V 1 AB
C20 VCEAB31VW227M U Capacitor 220 uF 35V 1 AB
C21 VCEAB31VW106M U Capacitor 10 uF 35V 1 AB
C22 VCEAB31HW104M U Capacitor 0.1 uF 50V 1 AM
C40 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C41 VCEAB31CW476M U Capacitor 47 uF 16V 1 AA
C42 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C43-44 VCKYD11CY103N U Capacitor 0.01 uF 16V 2 AB
C50 VCCCF61HH330J U Capacitor 33 pF 50V 1 AB
C70 VCEAB31VW476M U Capacitor 47 uF 35V 1 AB
C71 VCEAB31VW107M U Capacitor 100 uF 35V 1 AB
C80 VCKYD11CY103N U Capacitor 0.01 uF 16V 1 AA
VCKYF31HF331N U Capacitor 330 uF 50V 1 AA
D1-3 VHD1N4005E61B U Diode (11ES1) 3 AE
D10 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
D20 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
D70-71 VHD1N4005E61B U Diode (1N4005E) 2 AE
D72-74 VHD1SS270A/-1 U Diode (1SS270ATA) 3 AA
D80 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
IC1 RH-IZA919DRE0 U LSI 1 AS
LED1-3 VHPSLP7117E-3 U Light emitting diode 3 AC
Q20 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q21 VSKRC105M//-3 U Transistor (KRC105M) 1 AB
Q30 VSKRC101M//-3 U Transistor (KRC101M) 1 AA
Q40 VS2SA1267Y/-3 U Transistor (2SA1267Y) 1 AC
Q70 VSKRC105M//-3 U Transistor (KRC105M) 1 AB
∆∆
ELECTRIC PARTS
REF NO PART NO § DESCRIPTION Q'TY CODE
1-1 FH-DZA035WRE0 U H.V. rectifier assembly 1 AP
1-2 FPWBFA308WRE2 U Noise filter 1 AQ
1-3 QACCBA032WRE3 U Power supply cord 1 AR
SW3 QSW-MA131WRE0 U Stop switch 1 AK
MG RV-MZA264WRE0 U Magnetron 1 BK
C RC-QZA238WRE0 U High voltage capacitor 1 AR
SW1 QSW-MA131WRE0 U Monitored latch switch 1 AK
SW2 QSW-MA133WRE0 U Monitor switch 1 AN
FM RMOTEA361WRE0 U Fan motor 1 AT
F2 QFS-CA025WRE0 U Fuse F8A 1 AC
OL RLMPTA066WRE0 U Oven lamp 1 AK
TTM RMOTDA227WRE0 U Turntable motor 1 AU
TC1 RTHM-A098WRE0 U Thermal cut-out 125°C (Magnetron) 1 AH
TC2 RTHM-A098WRE0 U Thermal cut-out 125°C (Oven) 1 AH
T RTRN-A016URE1 U Power transformer 1 BE
REF NO PART NO § DESCRIPTION Q'TY CODE
2-1 GCABUA024URP0 U Outcase cabinet (SL) 1 AX
2-1 GCABUA469WRT0 U Outer case cabinet (W) 1 AX
2-1 GCABUA005URP0 U Outercase cabinet (G) 1 AX
2-2 GDAI-A219WRP5 U Base plate assembly 1 AS
2-3 GLEGPA028WRE0 U Foot 4 AA
