PART LIST
R1-5 VRS-L63DA102J U Resistor 1.0k ohm 2W 5 AB
R10-11 VRD-B12EF273J U Resistor 27k ohm 1/4W 2 AA
R12 VRD-B12EF103J U Resistor 10k ohm 1/4W 1 AA
R20 VRD-B12EF822J U Resistor 8.2k ohm 1/4W 1 AB
R30 VRD-B12EF332J U Resistor 3.3k ohm 1/4W 1 AA
R31 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R40 VRD-B12HF152J U Resistor 1.5k ohm 1/2W 1 AA
R41 VRD-B12EF102J U Resistor 1.0k ohm 1/4W 1 AA
R42 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R50 VRN-B12EK103F U Resistor 10k ohm 1/4W 1 AA
R64-65 VRD-B12EF104J U Resistor 100k ohm 1/4W 2 AA
R70-71 VRS-B13AA361J U Resistor 360 ohm 1W 2 AA
R72 VRD-B12EF822J U Resistor 8.2k ohm 1/4W 1 AB
R73 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R80 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R81 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A094DRE0 U Relay (OMIF-S-112LM) 1 AL
SP30 RALM-A014DRE0 U Buzzer (PKM22EPT-THAI) 1 AG
SW1-4 QSW-PA004DRE0 U Tact switch 4 AB
SW5-7 QSW-PA016DRE0 U Tact switch 3 AB
VRS1 RH-VZA032DRE0 U Varistor (10G471K) 1 AC
ZD1 VHEHZ12C1//-1 U Zener diode (HZ12C1) 1 AA
ZD20-21 VHEHZ12C1//-1 U Zener diode (HZ12C1) 2 AA
ZD40 VHEHZ4C3///-1 U Zener diode (HZ4C-3) 1 AA
ZD70-71 VHEHZ7C2///-1 U Zener diode (HZ7C2) 2 AA
3- 2-1 PSHEPA041URE0 U Key sheet[R-343(W)M] 1 AL
3- 2-1 PSHEPA042URE0 U Key sheet [R-343(G)M] 1 AM
3- 2-1 PSHEPA044URE0 U Key sheet [R-343(SL)M] 1 AM
3- 2-2 GMADIA006URF0 U Display window 1 AF
3- 2-3 GCOVHA014URF0 U Key fixing frame 1 AL
3- 3 HPNLCA028URF0 U Control panel frame [R-343(W)M] 1 AN
3- 3 HPNLCA030URF0 U Control panel frame [R-343(G)M] 1 AN
3- 3 HPNLCS004URR0 U Control panel frame [R-343(SL)M] 1 AN
3- 4 JBTN-A017URF0 U Open button [R-343(W)M] 1 AE
3- 4 JBTN-A061URF0 U Open button [R-343(G)M] 1 AE
3- 4 JBTN-R005URF0 U Open button [R-343(SL)M] 1 AE
3- 5 MSPRCA045WRE0 U Open spring 1 AA
REF NO PART NO § DESCRIPTION Q'TY CODE
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§' mark : Spare part delivery section.
OVEN PA\RTS
REF NO PART NO § DESCRIPTION Q'TY CODE
CONTROL PANEL PARTS CONTINUED
4-2 LBNDKA107WRP1 U Capacitor holder 1 AD
4-3 PHOK-A078WRF5 U Latch hook 1 AH
4-4 NFANJA001URE0 U Fan blade 1 AF
4-5 PDUC-A637WRF2 U Fan duct 1 AL
4-6 LANGFA155WRP7 U Chassis support 1 AF
4-7 PPACGA108WRE0 U Packing 1 AC
4-9 MLEVPA001URF3 U Open lever 1 AE
4-10 NCPL-A042WRF1 U Coupling 1 AD
4-11 PCOVPA308WRE1 U Waveguide cover 1 AE
4-12 PFILWA042WRP0 U Lamp filter 1 AB
4-14 PDUC-A606WRF1 U Air intake duct 1 AK
4-15 PCUSGA317WRP0 U Absorb cushion 2 AA
4-16 PCUSUA340WRP2 U Air deflector 1 AA
4-20 PCUSGA273WRP0 U Cushion 1 AC
4-23 PSPAGA001WRE0 U Vib proof cushion 1 AA
