R343M - 19
PART LIST
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§ 'mark : Spare part delivery section.
*
*
*
*
DOOR PARTS
REF NO PART NO § DESCRIPTION Q'TY CODE
5-1 DDORFA749WRK0 U Door panel assembly 1 AY
5-2 GCOVHA352WRF2 U Choke cover 1 AH
5-3 GWAKPW012URR0 U Door frame (W) 1 AP
5-3 GWAKPA003URR0 U Door frame (G) 1 AP
5-3 GWAKPS002URR0 U Door frame (SL) 1 AP
5-4 PGLSPA020URR0 U Door screen 1 AX
5-5 LSTPPA147WRF1 U Latch head 1 AE
5-6 MSPRTA141WRE0 U Latch spring 1 AA
5-7 PSHEPA457WRE0 U Door film 1 AF
5-8 FDORFA287WRT0 U Door panel sub assembly 1 AW
5-9 XEBSD30P06000 U Screw 3mm x 6mm 6 AA
5-10 LSTPPA003URF0 U Glass stopper 1 AB
MISCELLANEOUS
REF NO PART NO § DESCRIPTION Q'TY CODE
6-1 FROLPA002URK0 U Roller stay 1 AM
6-2 NTNT-A051WRE0 U Turntable tray 1 AN
6-3 TINS-A191URR0 U Instruction book 1 AS
6-5 QW-QZA210WRE1 U H.V. wire B 1 AD
6-6 FW-VZA020URE1 U Main wire harness 1 AU
6-7 TCAUHA001WRR1 U Caution label 1 AC
SCREWS, NUTS AND WASHERS
REF NO PART NO § DESCRIPTION Q'TY CODE
7-1 XWWSD50-06000 J Washer 1 AA
7-2 XHTSD40P08RV0 J Screw 4mm x 8mm 3 AA
7-3 XEPSD40P25000 J Screw 4mm x 25mm 2 AA
7-4 LX-LZA011WRE0 U Rivet 2 AB
7-5 LX-CZA001URE0 U Self tapping screw 16 AA
7-6 XHPSD40P60000 J Screw 4mm x 6mm 2 AA
7-7 XEBSD30P06000 J Screw 3mm x 6mm 1 AA
7-8 XFPSD50P10KS0 J Screw 4mm x 10mm 2 AB
7-9 XOTSE40P12000 U Cabinet screw (silver) 4 AA
7-9 XOTSF40P12000 U Cabinet screw (black) 4 AA
7-10 LX-EZA045WRE0 U Screw
(Not shown on illustration) 1 AA
7-11 XOTSD40P12RV0 J Self tapping screw 2 AA
7-12 XHPSD40P08K00 U Screw 1 AA
To Next Page
