R-350F
30
∆
*
*
*
*
∆
*
*
*
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA147WRZZ 1st. latch switch/ 2nd. interlock relay control switch 2 AG
1- 1 QSW-MA085WRE0
1st. latch switch/ 2nd. interlock relay control switch (Interchangeable)
2AF
1- 1 QSW-MA137WRE0
1st. latch switch/ 2nd. interlock relay control switch (Interchangeable)
2AH
1- 2 FPWBFA354WRKZ Noise filter 1 AY
1- 2 FPWBFA353WRKZ Noise filter (Interchangeable) for production use 1--
1- 3 QSW-MA148WRZZ Monitor switch 1 AF
1- 3 QSW-MA086WRE0 Monitor switch (Interchangeable) 1 AF
1- 3 QSW-MA138WRE0 Monitor switch (Interchangeable) 1 AH
1- 4 RTHM-A127WRZZ Thermal cut-out 125˚C (Oven) 1 AK
1- 5 QACCAA049WRZZ Power supply cord 1 AW
1- 5 QACCAA047WRE0 Power supply cord (Interchangeable) 1 AP
1- 6 FH-DZA088WRK0 High voltage rectifier assembly 1 AP
1- 6 FH-DZA094WRKZ High voltage rectifier assembly (Interchangeable) 1 AU
1- 7 RC-QZA293WRZZ High voltage capacitor 1 AV
1- 7 RC-QZA273WRZZ High voltage capacitor (Interchangeable)for production use 1--
1- 8 RV-MZA295WRE0 Magnetron 1 BF
1- 9 RMOTEA403WRZZ Fan motor 1 AZ
1- 9 RMOTEA340WRE0 Fan motor (Interchangeable) 1 AX
1- 9 RMOTEA389WRE0 Fan motor (Interchangeable) for production use 1--
1-10 QFS-CA026WRZZ Fuse F10A 1 AH
1-11 RLMPTA083WRZZ Oven lamp 1 AM
1-12 RMOTDA226WRE0 Turntable motor 1 AT
1-12 RMOTDA173WRE0 Turntable motor (Interchangeable) 1 AX
1-12 RMOTDA169WRE0 Turntable motor (Interchangeable) 1 AW
1-12 RMOTDA230WRE0 Turntable motor (Interchangeable) for production use 1--
1-13 RTHM-A117WRE0 Thermal cut-out 95˚C (MG) 1 AK
1-13 RTHM-A079WRE0 Thermal cut-out 95˚C (MG) (Interchangeable) 1 AH
1-14 RTRN-A680WRZZ Power transformer 1 BM
1-15 QFS-IA002WRE0 High voltage fuse 0.75A 1 AQ
CABINET PARTS
2- 1 GCABUA834WRPZ Outer case cabinet 1 BD
2- 2 GDAI-A343WRWZ Bottom plate 1 AX
2- 3 GLEGPA074WRE0 Foot 1 AC
CONTROL PANEL PARTS
3- 1 DPWBFC084WRKZ Power unit (New Zealand only) 1 BB
3- 1A QCNCMA446DRE0 2-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA232DRE0 12pin lead wire (CN-C) 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M Capacitor 10 uF 35V 2 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 Diode (1SS270ATA) 4 AA
Q2 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q3 VSKRC243M//-3 Transistor (KRC243M) 1 AB
R2 VRS-B13AA511J Resistor 510 ohm 1W 1 AA
R3 VRD-B12HF391J Resistor 390 ohm 1/2W 1 AA
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A113DRE0 Relay (DU24D1-1P(M)R) 1 AM
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA112DRE0 Transformer 1 AS
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
3- 2 DPWBFC276WRKZ CPU unit 1 BH
3- 3 FPNLCB657WRKZ Control panel frame with key unit 1 BA
3- 3-1 FUNTKB123WREZ Key unit 1 AX
3- 4 PSHEPA672WRE0 LED sheet 1 AK
3- 5 LHLD-A185WRF0 LCD holder 1 AL
3- 6 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PCUSUA235WRP0 Cushion 1 AE
4- 2 PPACGA084WRF0 TTM packing 1 AF
4- 3 PHOK-A116WRFZ Latch hook 1 AH
4- 4 LBNDKA143WRW0 Capacitor holder 1 AC
4- 5 NFANJA043WRE0 Fan blade 1 AK
4- 6 PDUC-A790WRWZ Fan duct 1 AZ
