30
R-3A88
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
∆
∆
∆
∆
∆
(J35) VRD-B12EF511J Resistor 510 ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 Relay (OJ-SS-124LM) 1 AG
RY2 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
SP40 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA098DRE0 Transformer 1 AT
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD2 VHEHZ4C3///-1 Zener diode (HZ4C-3) 1 AA
3- 2 FPNLCB225WRK0 Control panel frame with key unit 1 AZ
3- 2-1 FUNTKA753WRE0 Key unit 1 AV
3- 3 JBTN-A927WRF0 Open button 1 AF
3- 4 MSPRCA050WRE0 Open button spring 1 AB
3- 5 XEPSD30P08XS0 Screw : 3mm x 8mm 2 AA
OVEN PARTS
4- 1 PHOK-A095WRF0 Latch hook 1 AN
4- 2 LBNDKA095WRP0 Capacitor holder 1 AM
4- 3 NFANJA029WRE0 Fan blade 1 AL
4- 4 PDUC-A599WRP0 Fan duct 1 AK
4- 5 FOVN-A333WRT0 Oven cavity 1 BD
4- 6 LANGFA171WRP0 Chassis support 1 AG
4- 7 MLEVPA194WRF0 Switch lever 1 AG
4- 8 NCPL-A045WRF0 Coupling 1 AH
4- 9 PCOVPA275WRE0 Waveguide cover 1 AR
4-10 PCUSGA339WRP0 Cushion 1 AG
4-11 PCUSUA329WRP0 Cushion 1 AC
4-12 PDUC-A597WRF0 Air guide 1 AG
4-13 PFILWA041WRE0 Lamp filter 1 AF
4-14 PPACGA084WRF0 TTM packing 1 AF
4-15 LANGQA368WRP0 Fuse angle 1 AL
4-16 LANGQA343WRP0 Thermal cut-out (Fan) mounting angle 1 AK
4-17 PCUSGA378WRP0 Cushion 1 AL
4-18 PCUSGA388WRP0 Cushion 1 AK
4-19 PCUSUA278WRP0 Cushion 1 AC
DOOR PARTS
5- 1 FDORFA283WRT0 Door panel 1 AY
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GCOVHA342WRF0 Choke cover 1 AM
5- 4 GWAKPA354WRF0 Door frame 1 AN
5- 5 HPNL-A657WRR0 Door screen 1 AT
5- 6 LSTPPA139WRF0 Latch head 1 AF
5- 7 MSPRTA084WRE0 Latch spring 1 AB
5- 8 XCPSD40P06000 Screw; 4mm x 6mm 2 AA
MISCELLANEOUS
6- 1 FROLPA057WRK0 Roller stay 1 AQ
6- 2 NTNT-A051WRE0 Turntable tray 1 AR
6- 3 TINS-A568WRR0 Operation manual (English) 1 AQ
6- 4 FW-VZB045WRE0 Switch harness 1 AH
6- 5 FW-VZB494WRE0 Main wire harness 1 AW
6- 6 QW-QZA150WRE0 High voltage wire B 1 AF
6- 7 LHLDWA011WRE0 Purse lock “M” 1 AB
6- 8 TCAUHA214WRR0 Caution label 1 AC
6- 9 PSHE-A069WRR0 Menu label 1 AM
6-10 TSPCNC326WRR0 Name plate 1 AE
6-11 PZET-A012WRE0 Terminal insulator 1 AB
6-12 QTANP0020YBE0 Connector 1 AA
6-13 TCADCA565WRR0 Cook book (Thai) 1 AZ
6-14 QW-QZA177WRE0 Earth wire 1 AK
6-15 TLABPA032WRR0 Grounding label 1 AG
6-16 TINS-A567WRR0 Operation manual (Thai) 1 AQ
SCREWS,NUTS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 9 AA
7- 2 XFPSD30P06000 Screw : 3mm x 6mm 2 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
7- 4 XHTSD40P08000 Screw; 4mm x 8mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 14 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 9 AA
7- 7 XVPSD40P20000 Screw; 4mm x 20mm 1 AA
7- 8 XFPSD30P10000 Screw; 3mm x 10mm 1 AA
