Sharp R-9H58 - Parts List

R-9H58
37
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
∆
∆
ELECTRICAL PARTS
1- 1 FH-DZA058WRK0 High voltage rectifier assembly 1 AL
1- 2 FH-HZA041WRE0 Thermistor assembly 1 AN
1- 3 QACCAA043WRE0 Power supply cord 1 AW
1- 4 QFS-CA010WRE0 Fuse (M8A) 1 AE
1- 5 QFS-TA013WRE0 Temperature fuse 150˚C 1 AG
1- 6 FPWBFA287WRK0 Noise filter 1 AS
1- 7 QSOCLA022WRE0 Oven lamp socket 1 AG
1- 8 QSW-MA111WRE0 Monitor switch 1 AK
1- 9 QSW-MA110WRE0 Stop switch and Damper switch 2 AK
1-10 QSW-MA110WRE0 Upper and lower latch switches 2 AK
1-11 RC-QZA075WRE0 High voltage capacitor 1 AU
1-12 RHET-A139WRE0 Convection heater 1 AY
1-13 RLMPTA069WRE0 Oven lamp 1 AK
1-14 RMOTDA191WRE0 Damper motor 1 AS
1-15 RMOTDA097WRE0 Turntable motor 1 AV
1-16 RMOTEA303WRE0 Cooling fan motor 1 AX
1-17 RMOTEA284WRE0 Convection motor 1 AZ
1-18 RR-WZA003WRE0 Monitor resistor 0.8Ω 20W 1 AG
1-19 RTHM-A085WRE0 Thermal cut-out 150˚C (OVEN) 1 AL
1-20 RTHM-A079WRE0 Thermal cut-out 95˚C (FM) 1 AL
1-21 RTRN-A318WRE0 Power transformer 1 BP
1-22 RV-MZA114WRE0 Magnetron 1 BG
1-23 FDTCTA157WRK0 AH sensor assembly 1 AY
CABINET PARTS
2- 1 FDAI-A181WRY0 Base plate assembly 1 AR
2-1-1 GCOVHA156WRP0 Turntable motor cover 1 AB
2-1-2 XHTSD40P08RV0 Screw; 4mm x 8mm 1 AA
2- 2 FHNG-A092WRM0 Oven hinge (Lower) 1 AF
2- 3 GCABDA074WRW0 Rear cabinet 1 AG
2- 4 GCABUA463WRP0 Outer case cabinet 1 BF
2- 5 PHOK-A043WRF0 Latch hook 1 AM
2- 6 GFTARA001WRW0 Oven lamp access cover 1 AC
2- 7 GLEGPA019WRE0 Foot 4 AD
2- 8 LBNDKA036WRP0 Capacitor holder 1 AG
2- 9 LBSHC0032WRE0 Cord bushing 1 AB
2-10 LSTPPA141WRF0 Cord anchorage (Upper) 1 AD
2-11 LSTPP0009YBF0 Cord anchorage (Lower) 1 AC
2-12 MLEVPA122WRF0 Latch lever 1 AD
CONTROL PANEL PARTS
3- 1 CPWBFA706WRK0 Control unit (New Zealand only) 1 BT
3- 1A QCNCMA227DRE0 5-pin connector(A) 1 AC
3- 1B QCNCMA267DRE0 6-pin connector(E) 1 AC
3- 1C QCNCMA237DRE0 3-pin connector(F) 1 AD
3- 1D QCNCWA057DRE0 12-pin connector(G) 1 AF
3- 1E RV-KXA077DRE0 Fluorescent display tube 1 AY
3- 1F PCUSGA381WRP0 Cushion 2 AG
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C2 VCEAB31VW108M Capacitor 1000µF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C4 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C5 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C6 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C7-8 VCKYD11CY103N Capacitor 0.01µF 16V 2 AH
C9 VCTYF31HF103Z Capacitor 0.01µF 50V 1 AB
C10 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C11 VCEAB31EW226M Capacitor 22µF 25V 1 AA
C20 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C21 VCEAB31HW104M Capacitor 0.1µF 50V 1 AM
C22 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C30 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C50 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C60 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C70 RMPTEA009DRE0 Capacitor array 330pF x 4 1 AE
CF1 RCRS-A035DRE0 Ceramic resonator (CST4.19MGW) 1 AG
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D7 VHD1SS270A/-1 Diode (1SS270ATA) 1 AA
D20-26 VHD1SS270A/-1 Diode (1SS270ATA) 7 AA
D30-31 VHD1SS270A/-1 Diode (1SS270ATA) 2 AA
D70-77 VHD1SS270A/-1 Diode (1SS270ATA) 8 AA
IC1 RH-IZA736DRE0 LSI 1 AX
