R-9H58
38
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
IC2 RH-IZA495DRE0 IC 1 AL
Q1 VS2SB910MR/-4 Transistor (2SB910M) 1 AE
Q3 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q4 VSDTA123ES/-3 Transistor (DTA123E) 1 AA
Q20-23 VSKRA101M//-3 Transistor (KRA101M) 4 AB
Q24-25 VSKRA223M//-3 Transistor (KRA223M) 2 AB
Q26 VSKRC243M//-3 Transistor (KRC243M) 1 AB
Q40 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q90 VSKRA101M//-3 Transistor (KRA101M) 1 AB
R2 VRD-B12HF471J Resistor 470 ohm 1/2W 1 AA
R3 VRD-B12HF331J Resistor 330 ohm 1/2W 1 AA
R4 VRD-B12HF751J Resistor 750 ohm 1/2W 1 AA
R7-8 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R10-11 VRS-B13AA180J Resistor 18 ohm 1W 2 AA
R30 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R50 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R51 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R62 VRN-B12EK753F Resistor 75k ohm(F) 1/4W 1 AA
R63 VRN-B12EK101F Resistor 100 ohm(F) 1/4W 1 AA
R64 VRN-B12EK222F Resistor 2.2k ohm(F) 1/4W 1 AA
R70-81 VRD-B12EF332J Resistor 3.3k ohm 1/4W 12 AA
R90-93 VRD-B12EF104J Resistor 100k ohm 1/4W 4 AA
R100 VRS-B13AA331J Resistor 330 ohm 1W 1 AA
RY1-3 RRLY-A083DRE0 Relay (OMIF-S-118LM) 3 AK
RY4-6 RRLY-A078DRE0 Relay (OJ-SS-118LM) 3 AG
SP40 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA089DRE0 Transformer 1 AU
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD2 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
ZD3 VHEHZ5C2///-1 Zener diode (HZ5C-2) 1 AA
ZD4 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 FPNLCB249WRK0 Control panel frame with key unit 1 BB
3- 2-1 FUNTKA769WRE0 Key unit 1 BA
3- 2-2 HPNLCA800WRF0 Panel grill 1 AL
3- 3 JBTN-A766WRF0 Open button 1 AG
3- 4 MSPRCA050WRE0 Open button spring 1 AB
3- 5 LANGTA197WRW0 Control panel back plate 1 AK
3- 6 MLEVFA057WRW0 Open lever 1 AE
3- 7 NSFTTA042WRE0 Open shaft 1 AE
3- 8 XEPSD30P10XS0 Screw ; control unit mtg. 3 AA
3- 9 XCPSD40P12000 Screw ; control panel back plate mtg. 4 AA
OVEN PARTS
4- 1 FBRGMA002WRE0 Bearing assembly 1 AQ
4- 2 FDUC-A124WRW0 Steam duct assembly 1 AN
4- 3 NFANJA020WRE0 Cooling fan 1 AE
4- 4 FFTA-A034WRK0 Damper ass’y 1 AM
4- 5 FOVN-A316WRY0 Oven cavity 1 AX
4- 6 FROLPA072WRK0 Roller stay 1 AL
4- 7 LANGFA089WRW0 Chassis support 1 AE
4- 8 LANGQA407WRW0 Convection motor mounting plate 1 AG
4- 9 LANGQA213WRW0 Lamp socket mounting angle 1 AE
4-10 LANGQA369WRP0 Thermal cut-out mounting angle 1 AB
4-11 LANGTA196WRW0 Bearing mounting plate 1 AD
4-12 LBNDK0054WRE0 Heater element holder 2 AB
4-13 LFIX-A013WRW0 Bearing holder plate 1 AB
4-14 LHLDKA009WRF0 Cord holder 1 AD
4-15 MCAMPA030WRF0 Damper cam 1 AC
4-16 MHNG-A165WRM0 Oven hinge (upper) 1 AE
4-17 NBLTKA005WRE0 Convection fan belt 1 AF
4-18 NCPL-A021WRF0 Turntable coupling 1 AE
4-19 NFANMA019WRW0 Convection fan 1 AE
4-20 PCUSGA236WRP0 Cushion 1 AC
4-21 NPLYBA025WRF0 Pulley (F) 2 AC
4-22 NSFTTA114WRE0 Damper shaft 1 AB
4-23 NTNT-A019WRH0 Turntable tray 1 AT
4-24 PCOVPA301WRE0 Waveguide cover 1 AE
4-25 PCOVPA292WRF0 AH sensor cover 1 AD
4-26 PCUSGA410WRP0 Transformer cushion D 1 AD
4-27 PCUSUA424WRP0 Magnetron duct cushion 1 AG
4-28 PCUSUA196WRP0 Cushion 2 AD
4-29 PCUSUA425WRP0 Cushion 1 AG
4-30 PCUSUA197WRP0 Steam cushion C 2 AD
4-31 FDUC-A279WRK0 Heater duct assembly 1 AT
