Sharp R-9H58 - Page 41

R-9H58
39
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
∆
*
4-32 PDUC-A269WRW0 Damper duct 1 AK
4-33 PDUC-A270WRF0 Cooling fan duct 1 AL
4-34 PFPF-A138WRE0 Thermal protection sheet (Left) 1 AK
4-35 PREFHA028WRW0 Thermal protection plate (Left) 1 AS
4-36 PFPF-A139WRE0 Thermal protection sheet (Right) 1 AF
4-37 PGLSPA485WRE0 Oven lamp screen 1
4-38 PREFHA053WRW0 Thermal protection plate (Right) 1 AQ
4-39 PCUSUA167WRP0 Cushion 2 AF
4-40 PFPF-A064WRE0 Thermal protection sheet 1 AE
4-41 PSKR-A153WRW0 Air guide (Bottom) 1 AK
4-42 PSKR-A171WRW0 Magnetron air guide 1 AF
4-43 PSKR-A161WRW0 Air guide (Right) 1 AF
4-44 LANGQA065WRP0 Noise unit angle 1 AD
DOOR PARTS
5 CDORFA747WRK0 Door assembly, complete. 1 BS
5- 1 DDORFA711WRY0 Door panel 1 BG
5- 2 GCOVHA155WRF0 Choke cover 1 AP
5- 3 GWAKPA142WRF0 Door frame 1 AT
5- 4 HDECQA123WRF0 Door sash (right) 1 AF
5- 5 HDECQA124WRF0 Door sash (left) 1 AF
5- 6 LSTPPA045WRF0 Upper latch head 1 AB
5- 7 LSTPPA046WRF0 Lower latch head 1 AB
5- 8 MSPRTA163WRE0 Latch spring 1 AD
5- 9 NSFTTA044WRE0 Latch shaft 1 AC
5-10 PGLSPA487WRE0 Door glass 1 BC
MISCELLANEOUS
6- 1 FAMI-A087WRM0 High rack 1 AW
6- 2 FAMI-A088WRM0 Low rack 1 AW
6- 3 TCADCA546WRR0 Cook book 1 AZ
6- 4 TINSEA684WRR0 Operation manual 1 AK
6- 5 TLABNA191WRR0 Menu label 1 AD
6- 6 FW-VZB534WRE0 Main wire harness 1 BC
6- 7 QW-QZA202WRE0 High voltage wire A 1 AK
6- 8 TSPCNC359WRR0 Name plate 1 AF
6- 9 FW-VZB342WRE0 Thermistor harness 1 AN
6-10 TCAUHA214WRR0 Caution label 1 AF
SCREWS, NUTS AND WASHERS
7- 1 XHTSD40P08RV0 Screw; 4mm x 8mm 6 AA
7- 2 LX-BZ0202WRE0 Special screw 2 AB
7- 3 LX-CZA020WRE0 Special screw 6 AA
7- 4 XCTWW40P08000 Screw; 4mm x 8mm 2 AA
7- 5 XCBWW30P06000 Screw; 3mm x 6mm 4 AA
7- 6 LX-CZ0052WRE0 Special screw 2 AA
7- 7 XBPSD40P06KS0 Screw; 4mm x 6mm 2 AA
7- 8 XOTWW40P10000 Screw; 4mm x 10mm 13 AA
7- 9 XBPSD30P14K00 Screw; 3mm x 14mm 1 AA
7-10 XOTSD40P12RV0 Screw; 4mm x 12mm 11 AA
7-11 XBPSD40P25000 Screw; 4mm x 25mm 2 AA
7-12 XFPSD40P25000 Screw; 4mm x 25mm 2 AA
7-13 LX-CZA030WRE0 Special screw 2 AA
7-14 XBTWW40P06000 Screw; 4mm x 6mm 8 AA
7-15 XCPSD30P06000 Screw; 3mm x 6mm 5 AA
7-16 XWVSD60-07000 Washer; 6mm x 0.7mm 1 AA
7-17 XCPSD30P08X00 Screw; 3mm x 8mm 6 AA
7-18 XCPSD30P08000 Screw; 3mm x 8mm 3 AA
7-19 XCPSD40P08000 Screw; 4mm x 8mm 7 AA
7-20 XCTSD40P08000 Screw; 4mm x 8mm 7 AA
7-21 XFPSD30P08000 Screw; 3mm x 8mm 2 AA
7-22 XFPSD40P08K00 Screw; 4mm x 8mm 5 AA
7-23 XFPSD40P08000 Screw; 4mm x 8mm. 5 AA
7-24 XFPSD60P14JS0 Screw; 6mm x 14mm 2 AC
7-25 XNESD40-32000 Nut; 4mm x 3.2mm 4 AA
7-26 XNEUW40-32000 Nut; 4mm x 3.2mm 1 AA
7-27 XOTSE40P12000 Screw; 4mm x 12mm 4 AA
7-28 LX-WZA004WRE0 Washer 1 AA
7-29 XOTSD40P12000 Screw; 4mm x 12mm 8 AA
7-30 XWSUW40-10000 Washer; 4mm x 1mm 1 AA
7-31 LX-WZA022WRE0 Washer 1 AA
7-32 LX-CZA060WRE0 Special screw 1 AC
