RCD1200M

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PART

RANK

DESCRIPTION

[1] OVEN PARTS

ELECTRIC PARTS

1-1 FDTCTA239WRKZ AV Sensor assembly (Exhaust thermistor)

1-2 FMOT-A031WRKZ BP Exhaust motor assembly

1-3 QFS-TA015WRE0 AG Temperature fuse 120C (Oven)

1-4 DH-HZA017WRKZ AY Magnetron thermistor assembly

1-5 FACCDA122WREZ BG Power supply cord

1-6 FPWBFA383WRKZ AN Noise filter

1-8 QFS-BA011WRE0 AE UL fuse 12A

1-9 QFSHDA009WRE0 AG Fuse holder

1-10 RC-QZA322WRZZ AW High voltage capacitor

1-11 FH-DZA145WRZZ AP High voltag rectifier assembly

1-12 QSW-MA085WRE0 AF Secondary interlock/Door sensing switches

1-13 FFS-BA033WRKZ -- Monitor switch (V-5220Q) and fuse (20A) assembly

1-14 RV-MZA358WRZZ BG Magnetron

1-15 QFS-TA014WRE0 AG Temperature fuse 150C (Magnetron)

1-16 QSOCLA026WRZZ AF Oven lamp socket

1-17 RLMPTA086WRZZ AL Oven lamp

1-18 RMOT-A016WRZZ AP Fan motor (DC) (Exhaust fan)

1-19 RMOT-A026WRZZ BE Fan motor

1-20 RMOTDA209WRE0 AR Stirrer motor (Antenna motor)

1-21 RTRN-A768WRZZ BQ Power transformer

1-22 DPWB-A570DRKZ BA Microwave sensor unit

1-23 DPWB-A571DRKZ BA Antenna sensor unit

1-24 DPWB-A565DRKZ BF Power unit (Switching power supply unit)

1-25 DPWB-A568DRKZ BH Relay unit

CABINET PARTS

2-1 DDAI-A214WRKZ BM Bottom plate assembly

2-1-1 XNES740-32000 AC Nut; 4mm x 3.2mm

2-1-2 LX-BZA179WREZ AL Special screw

2-2 FFTASA076WRYZ AM Oven lamp access cover

2-2-1 PCUSUA651WRPZ AD Cushion

2-3 GCABUB125WRPZ BN Outer case cabinet

2-4 GCOVHA526WRPZ AH Motor protect cover

2-5 LANGKB285WRPZ AG Cavity fixing plate

2-6 PSHEGA011WREZ AM Rubber sheet L

2-7 PSHEPB279WREZ AH Rubber sheet S

2-8 TMAPCA783WRRZ AF Schematic diagram

2-9 PFPF-A299WREZ AL Damper sheet

2-10 PCUSGA756WRPZ AD Cabinet cushion

OVEN PARTS

4-1 FCAS-A026WRYZ AR Fan case assembly

4-2 DDUC-A071WRKZ AV Exhaust duct assembly

4-3 PCUSGA721WRPZ AG Cushion

4-4 LHLD-A314WRFZ AN PWB holder

4-5 LANGQA694WRWZ AM AC cord angle

4-6 LBSHC0006YBE0 AD Cord bushing

4-7 LANGQA699WRPZ AK Noise filter angle

4-8 LANGQA734WRPZ AH Filter angle

4-9 LBNDKA163WRPZ AK HV capacitor band

4-10 GCOVAA399WRWZ AS MG exhaust cover

4-11 GCOVAA398WRTZ AW Rear cover

4-12 PGIDHA069WRPZ AF Exhaust cover

4-13 JKNBKA801WRFZ AS Splash cover knob

4-14 PCOVPA479WRFZ BB Splash cover

4-15 GCOVPA023WRPZ BF Cover

4-16 PCOVPA515WRFZ AY Frame

4-17 DDUC-A072WRKZ AV Intake duct assembly

4-18 FFIL-A014WRKZ BA air fillter unit

4-18-1 LX-BZA178WREZ AM Filter stopper R

4-18-2 PFIL-A040WRYZ AW Air fillter

4-18-3 XREUW40-06000 AA Ring

4-19 FGLSPA069WRFZ BT Oven tray assembly

4-20 FHNG-A370WRYZ AT Upper hinge assy

* 4-21 ************* ** Oven cavity assembly (Not a replaceable part)

4-22 FPLT-A025WRYZ AZ Upper antenna assembly

4-23 FPLT-A026WRYZ BA Lower antenna assembly

4-24 MLEVCA001WRFZ AG Switch lever C

4-25 MLEVPA279WRFZ AG Switch lever A

4-26 MLEVPA280WRFZ AG Switch lever B

4-27 MSPRCA165WREZ AC Latch spring A

4-28 MSPRCA166WREZ AC Latch spring B

* 4-30 PHOK-A164WRFZ AM Latch hook

4-31 GCOVHA527WRPZ AG Bottom cover

4-32 GCOVPA020WRPZ AV Antenna cover

4-33 JKNBKA800WRFZ AM Antenna cover knob

4-34 LANGKB292WRPZ AM Support angle

4-35 LANGQA671WRPZ AM Lamp holder angle

4-36 LANGQA696WRPZ AF Capacitor unit angle

4-37 LANGQA702WRPZ AM Motor fixing angle

4-38 LSUB-A137WRPZ AE Face support angle

4-39 MHNG-A592WRPZ AP Lower hinge

4-40 NSFTPA045WRFZ AN Antenna shaft

4-41 PCLIC0018WRE0 AB Clip l
