Sharp R-CD1200M Service Manual

RCD1200M
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
4-42 PCOVPA480WRFZ AG Hinge cover
4-43 PCOVPA496WRFZ AK Sensor cover
4-44 PFILWA064WRPZ AF Lamp filter
4-45 PGLSPA720WREZ AH Lamp glass
4-46 PCUSGA761WRPZ AE Cushion
4-47 PSKR-A462WRPZ AF Partition angle S
4-48 GLEGPA033WRE0 AA Leg
4-49 GCOVPA022WRPZ AG Partition cover
4-50 PCUSGA745WRPZ AD Cushion B
4-51 PCUSGA750WRPZ AC Lamp cushion
4-52 PCUSGA751WRPZ AC Cav top cushion
4-53 PCUSGA752WRPZ AD Cav face cushion
4-54 PSHEPB323WREZ AF Insertion barrer
4-55 PSKR-A464WRPZ AK Partition angle L
4-56 PDUC-B056WRFZ AN Mag cool duct A
4-57 PCUSGA757WRPZ AF Filter cushion
4-58 PDUC-B046WRPZ AK Mag cool duct B
4-59 PCUSGA742WRPZ AF Rear cushion A
4-60 PCUSGA743WRPZ AF Rear cushion B
4-61 PCUSGA744WRPZ AF Rear cushion C
4-62 PCUSGA746WRPZ AG Rear cushion D
4-63 PCUSGA747WRPZ AD Rear cushion E
4-64 PCUSGA748WRPZ AF Rear cushion F
4-65 PCUSGA758WRPZ AN Cav back sheet
4-66 PCUSGA765WRPZ AC Cushion
4-67 PCUSGA766WRPZ AC Cushion
4-68 PCUSGA767WRPZ AC Cushion
4-69 PCOVPA522WRFZ Edge cap L
4-70 PCOVPA523WRFZ Edge cap R
MISCELLANEOUS
6-10 LBNDKA166WREZ AD Wire holder
6-11 LHLDWA063WREZ AF Wire holder
6-13 TCAUAA316WRRZ AH caution label
6-14 TCAUAA312WRRZ AF monitor caution
6-15
TCAUAA313WRRZ AG hwc caution
6-16 TCAUAA314WRRZ AF caution label
6-17 TCAUAA315WRRZ AG user caution label
SCREWS, NUTS AND WASHE
7-1 LX-NZ0061WRE0 AA Nut : 4mm x 3.2mm
7-2 XHPS740P08000 AB Screw : 4mm x 8mm
7-3 XEPS730P08XS0 AB Screw : 3mm x 8mm
7-4 XHPS740P08K00 AB Screw : 4mm x 8mm
7-5 XBTUW40P12000 AB Screw : 4mm x 12mm
7-6 XOTS740P08000 AA Screw : 4mm x 8mm
7-7 XHTS740P08000 AC Screw : 4mm x 8mm
7-8 XBPS730P28KS0 AB Screw : 3mm x 28mm
7-9 XNES730-24000 AE nut : 3mm x 2.4mm
7-10 LX-BZA164WREZ AC HEX cup-screw
7-11 LX-BZA181WREZ AH Special screw
7-12 XETS740P08000 AA Screw : 4mm x 8mm
7-13 XHPS730P06000 AB Screw : 3mm x 6mm
7-14 LX-CZ0052WRE0 AA Special screw
7-15 XNGUW40-24000 AE Nut : 4mm x 2.4mm
7-16 LX-BZA132WREZ AB Special screw
7-17 LX-BZA138WREZ AB Special screw
7-18 XETS740P10000 AA Screw : 4mm x 10mm
7-19 LX-CZA085WREZ AB Special screw
7-20 XHTWW40P08000 AC Screw : 4mm x 8mm
7-21 XOTWW40P08000 AB Screw: 4mm x 8mm
7-22 XFPWW30P06000 AD Screw : 3mm x 6mm
7-23 XCBWW30P08000 AB Screw : 3mm x 8mm
7-24 XCPS740P08000 AB Screw : 4mm x 8mm
7-25 XBPS740P35000 AD Screw : 4mm x 35mm
7-26 XNES740-32000 AC Nut; 4mm x 3.2mm
7-27 LX-BZA169WREZ AC Special screw
7-28 XOTWW40P10000 AA Screw : 4mm x 10mm
7-29 XCHWW40P08000 AB Screw : 4mm x 8mm
[1] OVEN PARTS
