24
SJ-58L-A2
SJ-63L-A2
SJ-68L-A2/R2
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST(SJ-58L-A2G/A2B/A2L)
ELECTRIC PARTS
1-1 RTHM-A097CBEZ F-thermostat 1 1 1 AX
1-2 RSTT-A137CBE0 Starting relay 1 1 1 AL
1-3 QSWTDA025CBE0 Defrost timer 1 1 1 AW
1-4 PDMP-A046CBEZ Damper thermo 1 1 1 AX
1-5 FTHM-A028CBKZ Defrost thermo. ass’y 1 1 1 AN
1-6 RMOTRA036CBE0 Fan motor 1 1 1 AW
1-7 QSOCAA073CBEZ Lamp socket 1 1 1 AN
1-8 RLMP-A002CBE0 Lamp 1 1 1 AE
1-9 QACC-A133CBE0 Source cord 1 1 1 AN
1-10 QSW-PA090CBZA Door switch 1 1 1 AS
1-11 RHOG-A150CBEZ Protector 1 1 1 AN
1-17 FFS-TA055CBKZ Fuse ass’y 1 1 1 AL
1-20 FW-VZA143CBEZ Lead ev-cover ass’y 1 1 1 AL
1-21 FHETBA145CBEZ Def. Heater ass’y 1 1 1 BB
1-22 FCNW-A577CBK0 Relay cord s ass’y 1 1 1 AH
1-27 RMOTRA060CBEZ Fan motor(R-fan motor) 1 1 1 AV
1-28 RLMP-A028CBEZ Lamp15w 1 1 1 AG
1-29 QSOCAA072CBEZ Lamp socket 1 1 1 AN
1-30 FTHM-A027CBKZ R fan thermo ass’y 1 1 1 AQ
MECHANICAL PARTS
2-2 JKNB-A036CBFB F-temp. control knob 1 1 1 AD
2-4 LPLTMA568CBEZ Fl plate al. 1 1 1 AF
2-7 FLEGPA077CBKZ Leg holder l ass’y 1 1 1 AQ
2-7-1 FAJS-A009CBK0 Adjustable leg ass’y 2 2 2 AD
2-7-2 LHLD-A533CBPZ Leg holder l 1 1 1 AL
2-8 FLEGPA078CBKZ Leg holder r ass’y 1 1 1 AQ
2-8-2 LHLD-A534CBPZ Leg holder r 1 1 1 AP
2-11 PSPAVA074CBEA Bottom hinge spacer 1 1 1 AD
2-12 PSPAVA075CBEA Center hinge spacer 1 1 1 AD
2-13 DHNG-A363CBMZ Upper hinge ass’y 1 1 1 AE
2-14 DHNG-A365CBMZ Bottom hinge r ass’y 1 1 1 AE
2-15 DHNG-A364CBMZ Center hinge r ass’y 1 1 1 AF
2-16 GCOV-A191CBFZ E.v cover 1 1 1 AS
2-17 LCRA-A010CBE0 Fan clamp 2 2 2 AD
2-19 LHLD-A389CBF0 Motor cushion 2 2 2 AF
2-20 NFANPA020CBFA Propeller fan 100 1 1 1 AE
2-21 PSEL-B845CBEZ E.v cover sealer a 1 1 1 AC
2-22 PSEL-B846CBEZ E.v cover sealer b 1 1 1 AC
2-23 PSEL-A415CBE0 E.v cover sealer c 1 1 1 AC
2-24 PCOVPA175CBFA Terminal cover 1 1 1 AF
2-25 PCOV-A253CBFA F lamp cover 1 1 1 AC
2-26 PCOV-A254CBFA R lamp cover 1 1 1 AF
2-27 GCOVPA117CBRA R-c box cover 1 1 1 AT
2-28 HGRL-A182CBRA Fan louver 1 1 1 AW
2-29 GCOV-A162CBFG Upper hinge cover 1 - - AD
2-29 GCOV-A162CBFB Upper hinge cover - 1 - AD
2-29 GCOV-A162CBFK Upper hinge cover - - 1 AL
2-30 PCOV-A255CBFA Fan cover 2 2 2 AD
2-31 JKNB-A033CBFB R-temp. control knob 1 1 1 AD
2-36 PCAP-A006CBFX Screw cover 2 - - AB
2-36 PCAP-A006CBFS Screw cover - 2 - AB
2-36 PCAP-A006CBFU Screw cover - - 2 AB
2-37 PCAP-A056CBFF Screw cover b 2 2 2 AC
2-38 PGID-A156CBFZ R air guider a 1 1 1 AG
2-41 PSEL-B848CBEZ A-sealer thermo. cap 1 1 1 AC
2-49 LSTPPA108CBFA Chilled stopper 2 2 2 AC
2-50 NFANPA019CBFA Propeller fan 80 1 1 1 AM
2-51 PBOX-A121CBFA F lamp box 1 1 1 AF
2-52 PBOX-A122CBFA R lamp box 1 1 1 AM
2-53 LHLD-A536CBFA R fan motor holder a 1 1 1 AF
2-54 LHLD-A537CBFA R fan motor holder b 1 1 1 AE
2-55 HGRL-A188CBFA Multi louver s 1 1 1 AG
2-56 PFPFPB248CBFZ R-louver insu. s 1 1 1 AE
2-57 PSEL-B861CBEZ A-sealer r-louver 2 2 2 AC
2-59 PCOV-A264CBEZ F lamp box cover 1 1 1 AC
2-63 LHLD-A484CBFA Fan motor holder b 1 1 1 AH
2-64 LHLD-A485CBFA Fan motor holder a 1 1 1 AH
2-65 PSEL-B209CBE0 U-sealer handle 2 2 2 AB
2-66 PSHEMA132CBP0 Heater cover al 1 1 1 AD
2-67 LPLTMA570CBPZ Drain support al 1 1 1 AE
2-69 PSEL-B847CBEZ E.v cover sealer d 2 2 2 AC
2-71 PSEL-A552CBE0 Dial sealer 1 1 1 AC
SJ- SJ- SJ-
58L-A2G 58L-A2B 58L-A2L
