Sharp SJ-D28N-SLG - Electrical Parts List

SJD24NSLG
4 – 1
SJD24NSLG
Service Manual
CHAPTER 4. LIST OF ELECTORICAL PARTS
ITEMS
TYPE NAME
Thermo. fuse
Defrost heater
Lamp
Compressor
Starting Relay
Overload Relay(Protector)
Main PWB
(D20/D24/D28)
SF70E
FL1152-SZ
FPWB-A451CBKZ
220-240V 378
220-240V/50Hz
Working temp. : 70 C
140W at 230V
Open/ Close : 120 / 61 C
Cooling capacity : 136W (50Hz)
Main coil : 23.8
Aux. coil : 42.4
(at 75 C)
W
Common
Aux. coil
Main coil
240V 15W
Door switch SDKNA20101 250V 0.25A 3 Terminals push-button type
RATING
SPECIFICATIONS
R Thermistor
Def.Thermistor
#187 StraightTerminal
125V 0.5 A
5TM149PFBYY-53
33 (at 25 C)
Running Capacitor
RC-EZA237CBZZ
400V 3˴(
Fan motor 3R00044B AC 200-240V, 50Hz
250V 10A
DC 5V R0 = 6.4 k , B(0) = 3811
DC 5V R0 = 6.4 k , B(0) = 3811
220-240V/50Hz
Main PWB
(D29) FPWB-A490CBKZ
220-240V/50Hz
50/60Hz
PGN0SBT
