Sharp SMD2489ES - Page 3

3
B
C
G
D
B
C
D
E
F
G
H
I
I
J
K
L
M
N
O
P
A
Q
A
F
E
Figure 3 represents a typical standard cabinet. If installed in
custom cabinets with extended countertops, take into account
visibility and access to controls. See Figure 4.
Move oven location downward for
extended countertops
Extended countertops
Figure 4
Figure 3
A. 25" (635 mm)
B.
1
/2" (12.7 mm) minimum
C. 16" (406.4 mm)
D. 36" (914.40 mm)
E. Control panel shown in
open position
F. 24" (609.60 mm)
G. 34
1
/2" (876.30 mm)
