6E
INSTALLATION INSTRUCTIONS
IMPORTANT: This appliance shall be installed only by authorized
persons and in accordance with the manufacturer’s installation
instructions, local gas tting regulations, municipal building codes,
electrical wiring regulations, local water supply regulations.
STEP 1 - UNPACK THE OVEN
WARNING
EXCESSIVE WEIGHT HAZARD
Use two or more people to move and install oven.
Failure to do so can result in back or other injury.
1 Using two or more people, remove the oven and set it on cardboard
to avoid oor damage.
NOTE: Do not use the handle or any portion of the front frame
for lifting.
2 Remove the shipping materials and tape from the oven.
3 Remove the hardware package from inside the bag containing
literature.
4 Remove and set aside racks and other parts from inside the oven.
5 Move the oven on the cardboard near where it will be installed.
STEP 2 - REMOVE THE OVEN DOOR
IMPORTANT: The oven door is heavy and fragile, and the door
front is glass. To avoid oven door glass breakage, use both hands,
and grasp only the sides of the oven door to remove.
1 Open the oven door.
2 Locate the door latches in both corners of the oven door, and rotate
the latches forward to the unlocked position.
Locked
Unlocked
3 Grasp the edges of the oven door with both hands and push the
oven door fully closed. Lift up and pull oven door toward you to
remove. Set the oven door(s) aside on a covered work surface.
STEP 3 - INSTALL OVEN
WARNING
EXCESSIVE WEIGHT HAZARD
Use two or more people to move and install oven.
Failure to do so can result in back or other injury.
1 Using two or more people, grasp the ceiling of the oven cavity and
lift the oven onto a table or platform even with the cutout opening.
NOTE: The surface must be able to support the following weight:
• Single Oven: 160 lb (73 kg)
• Double Oven: 290 lb (132 kg)
2 Feed the exible electrical supply conduit from the oven to the
junction box.
To Next Page
