Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
164
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU1101 VTUVT2W5UW250 J VHF Tuner AZ
å TU1102 VTUVT2W5UF250 J VHF Tuner AZ
INTEGRATED CIRCUITS
IC1101 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1102 VHiM62320FP-1Y J M62320FP AH
IC1103 VHiBA7655AF-1Y J BA7655AF AG
IC1104 VHiM52055FP-1Y J M52055FP AH
IC1105 VHiM62332FP-1Y J M62332FP AL
IC1106 VHPGPFM513T-1 J PhotoDiode AH
IC1107 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1108 VHiTC4052BT-1Y J TC4052BFT AF
IC3800 VHiMM1630AQ-1Q J MM1630AQ AU
IC3801 VHiMM1519XQ-1Q J MM1519XQ AW
IC3802 VHiNJM4565M-1Y J NJM4565M AE
IC3803 VHiBA05SFP+-1Y J BA05SFP-E2 AG
IC3804 VHiPQ20WZ51-1Y J PQ20WZ5U AF
IC3805 VHiBU4051FV-1Y J BU4051BCFV-E2 AF
IC3806 VHiPCA9516A-1Y J “PCA9516APW,118” AN
IC3807 VHi7WH126FU-1Y J TC7WH126FU AE
IC3808 VHiM62320FP-1Y J M62320FP AH
IC3809 VHiM62320FP-1Y J M62320FP AH
IC3810 VHiT7WH123U-1Y J TC7WH123FU AD
IC3811 VHiTC7S04U/-1Y J TC7S04FU AE
IC3812 VHiBU4051FV-1Y J BU4051BCFV-E2 AF
IC5701 VHiBA09SFP+-1Y J BA09SFP AG
IC5702 VHiBA08SFP+-1Y J BA08SFP-E2 AG
IC5704 VHiWM8728ED-1Y J WM8728SEDS/R AK
IC5705 VHiBA033FP/-1Y J BA033FP-E2 AG
IC5706 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC5708 VHiBA4560F+-1Y J BA4560F-E2 AD
TRANSISTORS
Q1101 VS2SA1530AR-1Y J 2SA1530AR AB
Q1102 VSDTC314TK/-1Y J DTC314TK AC
Q1103 VSDTC314TK/-1Y J DTC314TK AC
Q1104 VS2SA1530AR-1Y J 2SA1530AR AB
Q1105 VS2SC3928AR-1Y J 2SC3928AR AB
Q1106 VS2SC3928AR-1Y J 2SC3928AR AB
Q1107 VS2SC3928AR-1Y J 2SC3928AR AB
Q1108 VS2SC3928AR-1Y J 2SC3928AR AB
Q1110 VS2SC3928AR-1Y J 2SC3928AR AB
Q1111 VS2SC3928AR-1Y J 2SC3928AR AB
Q1112 VS2SA1530AR-1Y J 2SA1530AR AB
Q1115 VS2SC3928AR-1Y J 2SC3928AR AB
Q1117 VS2SC3928AR-1Y J 2SC3928AR AB
Q1118 VS2SC3928AR-1Y J 2SC3928AR AB
Q1119 VS2SA1530AR-1Y J 2SA1530AR AB
Q1120 VS2SC3928AR-1Y J 2SC3928AR AB
Q1121 VS2SC3928AR-1Y J 2SC3928AR AB
Q1122 VS2SA1530AR-1Y J 2SA1530AR AB
Q1125 VS2SA1530AR-1Y J 2SA1530AR AB
Q1127 VS2SC3928AR-1Y J 2SC3928AR AB
Q1130 VS2SA1530AR-1Y J 2SA1530AR AB
Q1131 VSUMG4N++++-1Y J UMG4N AB
Q1132 VS2SA1530AR-1Y J 2SA1530AR AB
Q1145 VS2SC3928AR-1Y J 2SC3928AR AB
Q1146 VS2SC3928AR-1Y J 2SC3928AR AB
Q1147 VS2SA1530AR-1Y J 2SA1530AR AB
Q1148 VS2SA1530AR-1Y J 2SA1530AR AB
Q1153 VS2SA1530AR-1Y J 2SA1530AR AB
Q1206 VS2SC3928AR-1Y J 2SC3928AR AB
Q3800 VS2SA1530AR-1Y J 2SA1530AR AB
Q3801 VS2SA1530AR-1Y J 2SA1530AR AB
Q3802 VS2SA1530AR-1Y J 2SA1530AR AB
Q3803 VS2SC3928AR-1Y J 2SC3928AR AB
Q3804 VS2SC3928AR-1Y J 2SC3928AR AB
Q3805 VSDTC314TK/-1Y J DTC314TK AC
Q3806 VSDTC314TK/-1Y J DTC314TK AC
DUNTKC736FE01/FE02/FE03
AV UNIT
Q3808 VS2SA1530AR-1Y J 2SA1530AR AB
Q3809 VS2SC3928AR-1Y J 2SC3928AR AB
Q3810 VS2SC3928AR-1Y J 2SC3928AR AB
Q3811 VS2SC3928AR-1Y J 2SC3928AR AB
Q3812 VS2SC3928AR-1Y J 2SC3928AR AB
Q3813 VSDTC114EE/-1Y J DTC114EE AB
Q3814 VS2SC3928AR-1Y J 2SC3928AR AB
Q3815 VSDTC144EE/-1Y J DTC144EE AA
Q3816 VSDTC144EE/-1Y J DTC144EE AA
Q3817 VSDTC144EE/-1Y J DTC144EE AA
Q3818 VSDTC144EE/-1Y J DTC144EE AA
Q3819 VSDTC144EE/-1Y J DTC144EE AA
Q3820 VSDTC144EE/-1Y J DTC144EE AA
Q5706 VSDTC114EE/-1Y J DTC114EE AB
Q5707 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D1100 VHD1SS355//-1Y J 1SS355 AB
D1101 VHD1SS355//-1Y J 1SS355 AB
D1102 RH-EX0674GEZZY J Zener Diode AB
D1103 RH-EX1250CEZZY J Zener Diode, 6.2V AB
D1104 RH-EX1264CEZZY J Zener Diode, 10V AB
D1105 RH-EX1264CEZZY J Zener Diode, 10V AB
D1106 RH-EX1264CEZZY J Zener Diode, 10V AB
D1107 RH-EX1264CEZZY J Zener Diode, 10V AB
D1108 RH-EX1264CEZZY J Zener Diode, 10V AB
D1109 VHD1SS355//-1Y J 1SS355 AB
D1111 RH-EX1264CEZZY J Zener Diode, 10V AB
D1112 RH-EX1234CEZZY J Zener Diode AE
D1113 RH-EX1234CEZZY J Zener Diode AE
D1114 RH-EX1234CEZZY J Zener Diode AE
D1115 RH-EX1234CEZZY J Zener Diode AE
D1128 RH-EX0674GEZZY J Zener Diode AB
D1129 VHD1SS355//-1Y J 1SS355 AB
D1130 RH-EX1250CEZZY J Zener Diode, 6.2V AB
D3801 RH-EX1264CEZZY J Zener Diode, 10V AB
D3802 RH-EX1264CEZZY J Zener Diode, 10V AB
D3804 RH-EX1264CEZZY J Zener Diode, 10V AB
D3805 RH-EX1264CEZZY J Zener Diode, 10V AB
D3806 RH-EX1264CEZZY J Zener Diode, 10V AB
D3807 RH-EX1264CEZZY J Zener Diode, 10V AB
D3808 VHDRB521S30-1Y J RB521S30 AC
D3810 RH-EX1264CEZZY J Zener Diode, 10V AB
D3811 RH-EX1264CEZZY J Zener Diode, 10V AB
D3812 RH-EX1264CEZZY J Zener Diode, 10V AB
D3813 VHDDAN217U+-1Y J DAN217U AB
D3814 VHDDAN217U+-1Y J DAN217U AB
D3815 VHDDAN217U+-1Y J DAN217U AB
D3816 VHDDAN217U+-1Y J DAN217U AB
D3817 VHDDAN217U+-1Y J DAN217U AB
D3818 VHDDAN217U+-1Y J DAN217U AB
D3827 VHDHSU119//-1Y J HSU119 AB
D3828 VHDHSU119//-1Y J HSU119 AB
D3829 VHDHSU119//-1Y J HSU119 AB
D3831 VHD1SS355//-1Y J 1SS355 AB
D3832 VHD1SS355//-1Y J 1SS355 AB
D3833 VHD1SS355//-1Y J 1SS355 AB
D3834 VHD1SS355//-1Y J 1SS355 AB
D5706 VHD1SS355//-1Y J 1SS355 AB
D5715 VHD1SS355//-1Y J 1SS355 AB
COILS
L1100 VPD9M100KR86NY J Peaking, 10µH AC
L1101 VPD9M100KR86NY J Peaking, 10µH AC
L1102 VPD9M100KR86NY J Peaking, 10µH AC
L1103 VPD9M1R0MR20NY J Peaking, 1µH AB
L1104 VPD9M1R0MR20NY J Peaking, 1µH AB
L1105 VPD9M1R0MR20NY J Peaking, 1µH AB
L1106 VPD9M1R0MR20NY J Peaking, 1µH AB
L3800 VPCNN100J1R6NY J Peaking, 10µH AB
CAPACITORS
C1100 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1101 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1102 VCAAPF0JJ107MY J 100 6.3V Electrolytic AF
C1103 VCKYCY1HB103KY J 0.01 50V Ceramic AA
