Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

175

TU-GD10U-T

TU-45GAD/T

LC-45GX6U/D/T

CABINET AND MECHANICAL PARTS

1 CANGTA143WJ01 J Rear Frame Ass’y AU

(TU-GD10U-T)

1 CANGTA143WJ02 J Rear Frame Ass’y

(LC-45GAD)

1 CANGTA143WJ03 J Rear Frame Ass’y

(LC-45GAT)

1-1

Not Available

– Rear Frame —

1-2 HiNDPB098WJSA J Rear Indicator AN

(TU-GD10U-T)

1-2 HiNDPB254WJSA J Rear Indicator

(LC-45GAD)

1-2 HiNDPB255WJSA J Rear Indicator

(LC-45GAT)

1-3 QEARZA020WJFW J Earth Spring, x2 AC

2 CCABAA469WJ03 J Chassis Frame Ass’y BB

2-1

Not Available

– Chassis Frame —

2-2 LHLDW1121GEZZ J Wire Holder, x2 AB

2-3 LHLDWA023WJKZ J Wire Holder AC

2-4 LHLDWA032WJZZ J Wire Holder AD

2-5 QEARBA010WJFW J Earth Spring AG

2-6 XJPSN30P08XS0 J Screw, x2 AA

2-7 LANGTA106WJFW J Fixing Metal AL

2-8 LANGTA107WJSA J Fixing Metal AM

3 CCABBA334WJ14 J Bottom Cabinet Ass’y AY

(TU-GD10U-T)

3 CCABBA334WJ15 J Bottom Cabinet Ass’y

(LC-45GAD)

3 CCABBA334WJ16 J Bottom Cabinet Ass’y

(LC-45GAT)

3-1

Not Available

– Bottom Cabinet —

3-2 GLEGGA034WJZZ J Rubber Leg, x4 AD

3-3 TLABZA764WJSA J Label AE

4 CCABBA407WJ02 J Top Cabinet Ass’y AY

(TU-GD10U-T)

4 CCABBA407WJ05 J Top Cabinet Ass’y

(LC-45GAD)

4 CCABBA407WJ06 J Top Cabinet Ass’y

(LC-45GAT)

4-1

Not Available

–Top Cabinet —

4-2 TCAUHA050WJSB J Caution Label

(TU-GD10U-T)

4-2 TCAUHA086WJSB J Caution Label

(LC-45GAD)

4-2 TCAUHA071WJSB J Caution Label AE

(LC-45GAT)

4-3 PSLDMA571WJZZ J Gasket AQ

5 CHLDZA240WJ01 J Fan Holder Ass’y AH

5-1

Not Available

– Fan Holder —

5-2 PSPAGA133WJZZ J Spacer, x4 AB

6 CHLDZA306WJ01 J Fan Holder Ass’y AH

6-1

Not Available

– Fan Holder —

6-2 PSPAGA133WJZZ J Spacer, x4 AB

7 CPNLCA122WJ04 J Front Panel Ass’y BG

(TU-GD10U-T)

7 CPNLCA122WJ05 J Front Panel Ass’y BD

(LC-45GAD/DAT)

7-1

Not Available

–Front Panel —

7-2 GCOVAA638WJSA J B-CAS Card Cover AK

7-3 GDORFA111WJSA J Door AY

(TU-GD10U-T)

7-3 GDORFA091WJSB J Door AW

(LC-45GAD/DAT)

7-4 HDECQA333WJSA J LED Decoration Cover AF

7-5 HiNDPA758WJSA J PC CARD Indication Label AE

7-6 HiNDPA832WJSB J Terminal Indication Label AF

7-7 JBTN-A252WJKA J Power Button AH

7-8 LANGTA121WJFW J Hinge Angle, x2 AC

7-9 LHLDZ3057GEZZ J Magnet Catch, x2 AE

7-10 LHLDZA323WJSA J Hinge Fixed Holder, x3 AL

7-11 MHNG-1072CEZZ J Hinge, x3 AH

7-12 PSPAGA191WJZZ J Spacer, x2 AB

7-13 PSPAZ0457CESA J Spacer AA

7-15 XEBSN30P08000 J Screw, x6 AA

8 CSLDMA450WJ01 J Digital Shield Ass’y AU

8-1

Not Available

– Shield —

8-2 PRDARA104WJFW J Heat Sink AF

8-3 XJPSN30P08XS0 J Screw, x2 AA

9 CANGTA118WJ01 J Tuner Earth Angle Ass’y AQ

9-1

Not Available

–Tuner Earth Angle —

9-2 PSPAHA328WJZZ J Spacer AC

9-3 QEARZA058WJZZ J Gasket, x2 AH

10 GCOVAA624WJKA J Side Shield(L) AN

11 GCOVAA625WJKA J Side Shield(R) AN

12 GCOVAA678WJKA J SD Cover AE

14 PMLT-A159WJZZ J Gasket AE

15 PRDARA135WJFW J Heat Sink AN

16 LBSHZA003WJZZ J Fan Bush, x8 AD

17 LHLDW1009CEZZ J Wire Holder AA

18 LHLDW1046CEZZ J Wire Holder AA

19 LHLDW1060CEZZ J Wire Holder AB

20 LHLDW1081GEZZ J Wire Holder AB

21 LHLDW1090GEZZ J Wire Holder AB

22 LHLDWA038WJZZ J Wire Holder AC

23 LX-BZ3434CEFN J System Cable, x2 AB

24 LX-NZ3047GEZZ J Nut AA

25 NFANR0120CEZZ J FAN AU

26 NFANR0126CEZZ J FAN AT

27 NSFTZ0134CEFW J Shaft, x6 AD

28 PSLDMA303WJFW J Front Shield AL

29 PSLDMA451WJFW J TMDS Shield AH

30 PSLDMA342WJFW J PC Card Shield AF

31 PSLDMA425WJFW J RCA Shield AD

33 DUNTKC259FE03 – AV SUB Unit (TU-GD10U-T) —

33 DUNTKC259FE11 – AV SUB Unit (TU-45GAD) —

33 DUNTKC259FE12 – AV SUB Unit (TU-45GAT) —

34 DUNTKC505FE01 – TMDS TX Unit —

(TU-GD10U-T)

34 DUNTKD051FE08 – TMDS TX Unit (TU-45GAD) —

34 DUNTKD051FE10 – TMDS TX Unit (TU-45GAT) —

35 DUNTKC544FE01 J PC CARD Unit BY

36 DUNTKC267FE40 –

DVI/HDMI Unit (TU-GD10U-T)

—

36 DUNTKC267FE57 – DVI/HDMI Unit (TU-45GAD) —

36 DUNTKC267FE58 – DVI/HDMI Unit (TU-45GAT) —

37 DKEYDC307FE19 J

DIGITAL Unit (TU-GD10U-T)

37 DUNTKC307FE35 J DIGITAL Unit (TU-45GAD)

37 DUNTKC307FE39 J DIGITAL Unit (TU-45GAT)

38 DUNTKC602DE01 –

FORONT Unit (TU-GD10U-T)

—

38 DUNTKC602DE04 – FORONT Unit (TU-45GAD) —

38 DUNTKC602DE05 – FORONT Unit (TU-45GAT) —

39 DUNTKC603DE01 – AUDIO INTERFACE Unit —

(TU-GD10U-T)

39 DUNTKC603DE04 – AUDIO INTERFACE Unit —

(TU-45GAD)

39 DUNTKC603DE05 – AUDIO INTERFACE Unit —

(TU-45GAT)

40 DUNTKC691FE01 J MAIN Unit (TU-GD10U-T) DM

40 DUNTKC691FE08 J MAIN Unit (TU-45GAD)

40 DUNTKC691FE10 J MAIN Unit (TU-45GAT)

41 DUNTKC736FE01 – AV Unit (TU-GD10U-T) —

41 DUNTKC736FE02 – AV Unit (TU-45GAD) —

41 DUNTKC736FE03 – AV Unit (TU-45GAT) —

42 RDENCA064WJZZ – POWER SUPPLY Unit —

(TU-GD10U-T/LC-45GAT)

42 RDENCA110WJZZ – POWER SUPPLY Unit —

(LC-45GAD)

43 RDENCA089WJZZ – DC/DC CONVERTER Unit —

44 B2SX4102BT J 1BIT AMP Unit BL

45 PSLDMA404WJFW J DVI Shield AF

46 LANGTA154WJN1 J AV Mount Angle AQ
