Ref. No. Part No. ★ Description Code
202
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
DIODE
å VA7802 RH-VXA018WJN1 J Varistor AD
TRANSFORMERS
å T7801 RCiLFA132WJZZ J Coil AG
(LC-45GX6U/6T)
å T7801 RCiLFA130WJZZ J Coil AG
(LC-45GX6D)
å T7802 RCiLFA132WJZZ J Coil AG
(LC-45GX6U/6T)
å T7802 RCiLFA130WJZZ J Coil AG
(LC-45GX6D)
CAPACITORS
å C7801 RC-FZ029SCEZZ J 0.22 AC275V AD
å C7802 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
(LC-45GX6U/6T)
å C7802 RC-KZ0089GEZZ J AC
(LC-45GX6D)
å C7803 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
(LC-45GX6U/6T)
å C7803 RC-KZ0089GEZZ J AC
(LC-45GX6D)
å C7804 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
(LC-45GX6U/6T)
å C7804 RC-KZ0089GEZZ J AC
(LC-45GX6D)
å C7805 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
(LC-45GX6U/6T)
å C7805 RC-KZ0089GEZZ J AC
(LC-45GX6D)
å C7806 RC-FZ029SCEZZ J 0.22 AC275V AD
RESISTORS
å R7801 RR-HZA011WJN1 J 560k 1W AC
å R7802 RR-HZ0008GEN1 J 3.9M 1W AC
å R7803 RR-HZ0008GEN1 J 3.9M 1W AC
MISCELLANEOUS PARTS
å F7801 QFS-D0013CEZZ J Fuse, 6.3A, 250V AE
FH7801 QFSHD1002CEZZ J Fuse Holder AA
FH7803 QFSHD1002CEZZ J Fuse Holder AA
å P7801 QSOCAA001WJZZ J Socket AL
P7802 QPLGN0270GEZZ J Plug, 2Pin(AC) AA
LUG7801 QLUGHA002WJZZ J Lug AB
LUG7802 QLUGHA002WJZZ J Lug AB
LUG7803 QLUGHA002WJZZ J Lug AB
LUG7804 QLUGHA002WJZZ J Lug AB
LANGQA013WJFW J Fixing Metal AH
XBSS830P08000 J Screw AA
DUNTKC504VJ01/08/10
LINE FILTER UNIT
FB6932 RBLN-A005WJZZY J Ferrite Bead AA
FB6933 RBLN-A005WJZZY J Ferrite Bead AA
FB6934 RBLN-A005WJZZY J Ferrite Bead AA
P6901 QCNCMA167WJZZ J Connector, 10Pin(LB) AD
P6902 QCNCMA169WJZZ J Connector, 20Pin(LT) AE
P6903 QPLGNA330WJZZY J Plug, 10Pin(RM) AC
SC6401 QSOCNA239WJZZY J Socket, 32Pin AP
SC6801 QSOCNA222WJZZY J Socket, 80Pin AH
SC6802 QSOCNA222WJZZY J Socket, 80Pin AH
LUG6901 QLUGHA006WJZZY J Lug AC
LUG6902 QLUGHA006WJZZY J Lug AC
LUG6903 QLUGHA006WJZZY J Lug AC
LUG6904 QLUGHA006WJZZY J Lug AC
LUG6905 QLUGHA006WJZZY J Lug AC
LUG6906 QLUGHA006WJZZY J Lug AC
DUNTKC479UJ01/11/12
BOTTOM LCD CONTROLLERUNIT(Continued)
