Sharp TU-GD10U-T User Manual

Ref. No. Part No. ★ Description Code
208
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
RDENCA083WJZZ
RDENCA086WJZZ
POWER SUPPLY UNIT(Continued)
D7104 95CD4103AC026 J Zener Diode MA8030-LTX AD
D7106 95CD4103AC023 J Zener Diode MA8240-M AD
D7107 95CD2071AQ002 J ERA92-02 AG
D7903 95CD2095AQ008 J 1SS355 AD
D7904 95CD2095AQ008 J 1SS355 AD
D7905 95CD4103AC023 J Zener Diode MA8240-M AD
D7906 95CD2095AQ008 J 1SS355 AD
D7907 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7908 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7909 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7910 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7911 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7912 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7913 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7914 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7915 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7916 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7917 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7918 95CD4103AC053 J Zener Diode MA8390-MTX AD
D7919 95CD4103AC015 J Zener Diode MA8100-M AD
D7921 95CD2095AQ008 J 1SS355 AD
D7922 95CD2095AQ008 J 1SS355 AD
D7923 95CD2095AQ008 J 1SS355 AD
D7927 95CD2092AQ002 J SC902-2 AG
D7931 95CD4103AC041 J Zener Diode MA8330-LTX AD
D7932 95CD4103AC013 J Zener Diode MA8091-M AD
D7933 95CD2095AQ008 J 1SS355 AD
D7941 95CD2092AQ002 J SC902-2 AG
D7942 95CD4103AC024 J Zener Diode MA8270 AD
D7943 95CD4103AC023 J Zener Diode MA8240-M AD
D7944 95CD2095AQ008 J 1SS355 AD
D7945 95CD2095AQ008 J 1SS355 AD
D7951 95CD2005BQ206 J ERC81-006 AL
D7952 95CD4103AC008 J Zener Diode MA8068-M AD
D7953 95CD2095AQ008 J 1SS355 AD
COILS
å L7001 95CL1208RS103 J Coil SC-05-E100JKH AU
L7101 95CL1185RS640 J Coil SN12-400JH AR
L7102 95CL1210RS182 J Coil HHB20-1R2A1880JH BC
TRANSFORMERS
å T6101 95CL2000WS001 J 2WS001 BB
å T6201 95CL2000WS001 J 2WS001 BB
å T6301 95CL2000WS002 J 2WS002 BB
å T7901 95CL2000DL150 J 2D150 AY
CAPACITORS
C6101 95CC3146YS151 J 150(KXW) 450V Electrolytic BA
C6103 95CC1094EQ101 J 100p 50V Ceramic AC
C6109 95CC1093AQ472 J 4700p 50V Ceramic AE
C6110 95CC1095EQ103 J 0.01 50V Ceramic AC
C6120 95CC2047MQ474 J 0.47 450V Film AP
C6121 95CC1094EQ222 J 2200p 50V Ceramic AE
C6122 95CC1093AQ472 J 4700p 50V Ceramic AE
C6123 95CC1094EQ101 J 100p 50V Ceramic AC
C6151 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C6152 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6153 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6154 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6155 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6156 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6157 95CC1095CQ224 J 0.22 25V Ceramic AD
C6158 95CC1095CQ104 J 0.1 25V Ceramic AC
C6181 95CC1095EQ472 J 4700p 50V Ceramic AC
C6182 95CC1093AQ472 J 4700p 50V Ceramic AE
C6183 95CC1094EQ471 J 470p 50V Ceramic AC
å C6191 95CC1384QS102 J 1000p(E) KH Ceramic AE
(LC-45GX6U/6T)
å C6192 95CC1384QS102 J 1000p(E) KH Ceramic AE
(LC-45GX6U/6T)
C6201 95CC3146YS151 J 150(KXW) 450V Electrolytic BA
C6203 95CC1094EQ101 J 100p 50V Ceramic AC
C6209 95CC1093AQ472 J 4700p 50V Ceramic AE
C6210 95CC1095EQ103 J 0.01 50V Ceramic AC
C6220 95CC2047MQ474 J 0.47 450V Film AP
C6221 95CC1094EQ222 J 2200p 50V Ceramic AE
C6222 95CC1093AQ472 J 4700p 50V Ceramic AE
C6223 95CC1094EQ101 J 100p 50V Ceramic AC
C6251 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C6252 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6253 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6254 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6255 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6256 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6257 95CC1095CQ224 J 0.22 25V Ceramic AD
C6258 95CC1095CQ104 J 0.1 25V Ceramic AC
C6281 95CC1095EQ472 J 4700p 50V Ceramic AC
C6282 95CC1093AQ472 J 4700p 50V Ceramic AE
C6283 95CC1094EQ471 J 470p 50V Ceramic AC
C6301 95CC3146YS151 J 150(KXW) 450V Electrolytic BA
C6303 95CC1094EQ101 J 100p 50V Ceramic AC
C6309 95CC1093AQ472 J 4700p 50V Ceramic AE
C6310 95CC1095EQ103 J 0.01 50V Ceramic AC
C6320 95CC2047MQ474 J 0.47 450V Film AP
C6321 95CC1094EQ222 J 2200p 50V Ceramic AE
C6322 95CC1093AQ472 J 4700p 50V Ceramic AE
C6323 95CC1094EQ101 J 100p 50V Ceramic AC
C6351 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C6352 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6353 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6354 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6355 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C6357 95CC1095CQ224 J 0.22 25V Ceramic AD
C6358 95CC1095EQ473 J 0.047 50V Ceramic AC
C6381 95CC1095EQ472 J 4700p 50V Ceramic AC
C6382 95CC1093AQ472 J 4700p 50V Ceramic AE
C6383 95CC1094EQ471 J 470p 50V Ceramic AC
å C6391 95CC1384QS102 J 1000p(E) KH Ceramic AE
(LC-45GX6U/6T)
å C6391 95CC1384QS471 J 470p(B)
(LC-45GX6D)
å C6392 95CC1384QS102 J 1000p(E) KH Ceramic AE
(LC-45GX6U/6T)
å C6392 95CC1384QS471 J 470p(B)
(LC-45GX6D)
å C7001 95CC2045QQ104 J 0.1(RE-C) AC250V Film AF
C7005 95CC1095EQ103 J 0.01 50V Ceramic AC
C7006 95CC10Q0CQ105 J 1 25V Ceramic AE
C7101 95CC2047MQ474 J 0.47 450V Film AP
C7102 95CC2047MQ474 J 0.47 450V Film AP
C7103 95CC2047MQ474 J 0.47 450V Film AP
C7104 95CC2047MQ474 J 0.47 450V Film AP
C7106 95CC3077MQ3R3 J 3.3(KMG) 450V Electrolytic AK
C7108 95CC1152BC106 J 10(B) 16V Ceramic AG
C7109 95CC10B2SQ470 J 47p 2kV Ceramic AD
C7110 95CC1095EQ104 J 0.1 50V Ceramic AC
C7111 95CC1095EQ104 J 0.1 50V Ceramic AC
C7112 95CC1094EQ471 J 470p 50V Ceramic AC
C7113 95CC1095EQ473 J 0.047 50V Ceramic AC
C7114 95CC1094EQ101 J 100p 50V Ceramic AC
C7115 95CC1094EQ471 J 470p 50V Ceramic AC
C7116 95CC1095EQ104 J 0.1 50V Ceramic AC
C7117 95CC1095EQ104 J 0.1 50V Ceramic AC
C7118 95CC1152BC106 J 10(B) 16V Ceramic AG
C7119 95CC1095EQ103 J 0.01 50V Ceramic AC
C7120 95CC1095EQ104 J 0.1 50V Ceramic AC
C7121 95CC30A0DQ330 J 33(ZL) 35V Electrolytic AE
C7122 95CC1095EQ104 J 0.1 50V Ceramic AC
C7123 95CC1095EQ104 J 0.1 50V Ceramic AC
(LC-45GX6U/6T)
C7130 95CC2046NQ104 J 0.1(ECQ-E) 630V Film AK
C7901 95CC3151YS101 J 100(KXG) 450V Electrolytic AX
C7903 95CC10B2SQ470 J 47p 2kV Ceramic AD
C7909 95CC1093AQ472 J 4700p 50V Ceramic AE
