Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
212
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
CABINET AND MECHANICAL PARTS
1 CCABAA657WJ01 J Front Cabinet Ass’y BR
1-1
Not Available
–Front Cabinet —
1-2 GCOVAA917WJSA J R/C LED Cover AG
1-3 HBDGBA039WJSA J Badge, SHARP AL
1-4 PSPAGA237WJZZ J Spacer, x2
1-5 PSPAHA376WJZZ J Spacer, x6 AC
1-6 PSPAKA083WJZZ J Spacer, x2 AB
1-7 PSPAKA084WJZZ J Spacer AA
2 CCABBA429WJ01 J Rear Cabinet Ass’y BY
(LC-45GX6U)
2 CCABBA530WJ01 J Rear Cabinet Ass’y BW
(LC-45GX6D)
2 CCABBA531WJ01 J Rear Cabinet Ass’y BW
(LC-45GX6T)
2-1
Not Available
– Rear Cabinet —
2-2 GCOVAA755WJKA J Hole Cover, x6 AC
2-3 GCOVAA838WJKA J Cover, x4 AE
2-4 GCOVAA931WJKA J Side Cover A, x4 AG
2-5 HiNDP5733CESB J AQUOS Label AD
2-6 HiNDPA754WJSA J Indicator AD
2-7 HiNDPA786WJSA J Indicator AE
2-8 HiNDPB131WJSA J Indicator AH
2-9 LHLDWA048WJKZ J Holder, x5 AB
2-10 LHLDWA059WJKZ J Holder AC
2-11 LHLDWA066WJZZ J Holder AF
2-12 LHLDZ0132CEZZ J Holder, x2 AD
2-13 PSPAKA081WJZZ J Spacer AA
2-14 XEBS930P10000 J Screw, x8 AA
3 CCOVAA921WJ01 J Control Cover Ass’y AV
3-1
Not Available
– Control Cover —
3-2 JBTN-A325WJKA J Power Button AH
3-3 JBTN-A326WJKA J Control Button AL
3-4 MSPRCA049WJFW J Power Button Spring AC
4 CCOVAA681WJ01 J Terminal Cover_up Ass’y AU
4-1
Not Available
–Terminal Cover_up —
5 CDAi-A122WJ08 J Stand Unit BP
5-1
Not Available
– Stand Base BC
5-2 LANGKA282WJSA J Base Angle —
5-3 PSPAZA476WJZZ J Spacer, x4 AC
5-4 PSPAZA477WJZZ J Spacer, x2 AD
5-5 PSPAZA530WJZZ J Spacer, x2 AD
5-6 XEBS940P10000 J Screw, x10 AB
6 CHNG-A078WJ01 J Stand Hinge Ass’y BP
6-1
Not Available
– Stand Hinge —
6-2 GDAi-A117WJF8 J Swivel Base AP
6-3 GDAi-A137WJSA J Stand Pole BB
6-4 LX-NZA013WJFN J Nut AE
6-5 PSPAZA580WJZZ J Spacer, x2
6-6 XCSS940P25000 J Screw, x5 AB
7 CCHSMA134WJ01 J Center Angle Unit BW
7-1
Not Available
– Center Angle —
7-2 LANGKA305WJFW J Stand Angle AW
7-3 LX-BZA046WJFN J Screw, x4 AA
7-4 PSPAHA432WJZZ J Spacer (bottom), x2 AC
7-5 PSPAHA433WJZZ J Spacer (side) AC
7-6 PSPAHA458WJZZ J Spacer C, x3 AB
8
Not Available
–
45” WIDE LCD PANEL Unit Ass’y
—
8-1 RLCDTA030WJZZ J 45” WIDE LCD PANEL Unit HE
8-2 CANGKA306WJ01 J Sheet Angle Ass’y (Bottom) BB
8-2-1
Not Available
– Sheet Angle (Bottom) —
8-2-2 PSPAKA071WJZZ J Spacer AQ
8-2-3 PSPAKA074WJZZ J Spacer AQ
8-3 CANGKA306WJ02 J Sheet Angle Ass’y (Top) BB
8-3-1
Not Available
– Sheet Angle (Top) —
8-3-2 PSPAKA086WJZZ J Spacer AR
8-3-3 PSPAKA087WJZZ J Spacer AR
8-4 CANGKA308WJ01 J Sheet Angle Ass’y (Side), x2 AU
8-4-1
Not Available
– Sheet Angle (Side), x2 —
8-4-2 PSPAKA072WJZZ J Spacer, x2 AM
8-5 CANGKA335WJ01 J Sheet Angle Ass’y (Bottom) AX
8-5-1
Not Available
– Sheet Angel (Bottom) —
8-5-2 PSPAZA466WJKZ J Spacer, x4 AB
8-6 CANGKA337WJ01 J Sheet Angle Side Ass’y, x2 AX
8-6-1
Not Available
– Sheet Angle Side, x2 —
8-6-2 LHLDZA419WJKZ J Holder, x2 AF
8-6-3 LHLDZA420WJKZ J Holder, x2 AF
8-6-4 XEPS730P08000 J Screw, x4 AA
8-7 CCHSMA131WJ02 J Chassis Ass’y CF
8-7-1
Not Available
– Chassis —
8-7-2 LANGHA005WJFW J Fixing Metal A AV
8-7-3 LANGHA006WJFW J Fixing Metal B AV
8-7-4 LANGHA007WJFW J Fixing Metal C AW
8-7-5 LANGHA008WJFW J Fixing Metal D AX
8-7-6 LANGHA009WJFW J Fixing Metal E AZ
8-7-7 LANGKA316WJFW J Fixing Metal Top BE
8-7-8 LANGKA317WJFW J Fixing Metal Bottom BE
8-7-9 LANGKA318WJFW J Side Angle, x2 AY
8-7-10 LANGKA319WJFW J Fixing Metal_R AY
8-7-11 LANGKA320WJFW J Fixing Metal_L AY
8-7-12 LANGKA322WJFW J Fixing Metal, x2 AN
8-7-13 LANGKA323WJFW J Fixing Metal, x2 AN
8-7-14 LANGKA345WJFW J PWB Angle AN
8-7-15 LANGKA349WJFW J Fixing Metal AS
8-7-16 LHLDWA043WJKZ J Holder, x8 AB
8-7-17 LHLDWA048WJKZ J Holder, x2 AB
8-7-18 LHLDWA058WJKZ J Holder AC
8-7-19 LHLDWA067WJKZ J Holder, x10 AC
8-7-20 LHLDWA069WJKZ J Holder, x5 AC
8-7-21 LHLDZA401WJKZ J Holder, x2 AN
8-7-22 LHLDZA402WJKZ J Lamp Clip, x24 AD
8-7-23 LHLDZA436WJKZ J Holder AH
8-7-24 LX-BZA046WJFN J Screw, x25 AA
8-7-25 PMiR-A042WJZZ J Mirror BM
8-7-26 PSPAGA187WJ00 J Spacer, x8 AB
8-7-27 PSPAHA330WJZZ J Spacer, x2 AE
8-7-28 PSPAHA338WJZZ J Spacer, x9 AB
8-7-29 TCAUZA031WJZZ J Caution Label AB
8-7-30 TLABNA966WJZZ J No. Label
8-7-31 XBBS730P05000 J Screw, x30 AA
8-7-32 XBPS730P08JS0 J Screw, x4 AB
8-7-33 XBPS740P16000 J Screw, x6 AA
8-7-34 XBSS730P06000 J Screw, x3 AA
8-7-35 XEBS730P08000 J Screw, x4 AA
8-8 KLMP-A029WJZZ J Lamp, x12 BC
8-9 LANGKA335WJFW J Sheet Angle (Top) AX
8-10 LHLDZA400WJKZ J Lamp Holder top, x2 AP
8-11 LX-BZA051WJF7 J Screw, x4 AB
8-12 LX-BZA080WJF7 J Screw, x8 AA
8-13 LX-BZA081WJF7 J Screw, x6 AA
8-14 LX-BZA088WJFN J Screw, x14 AA
8-15 LX-EZA015WJF7 J Screw, x6 AA
8-16 PCOVUA029WJZZ J Diffusion Panel BL
8-17 PSHEPA173WJZZ J Reflection/Deflection Sheet CE
8-18 PSHEPA174WJZZ J Prism Sheet BW
8-19 PSHEPA175WJZZ J Diffusion Sheet BB
8-20 PSPAGA233WJZZ J Shild Spacer, x2 AF
8-21 PSPAGA234WJZZ J Shild Spacer, x2 AF
8-22 PSPAGA235WJZZ J Shild Spacer, x4 AF
8-23 PSPAGA236WJZZ J Shild Spacer, x2 AG
9 CPNLSA031WJ01 J Speaker Panel Ass’y CE
9-1
Not Available
– Speaker Panel —
9-2 HDECQA440WJKB J Decoration Plate
9-3 HPNC-A071WJSA J Punching Metal CB
9-4 PSPAHA393WJZZ J Spacer, x2 AF
9-5 PSPAZA515WJZZ J Spacer AN
9-6 XEBSN26P06000 J Screw, x10 AA
10 CSLDMA544WJ01 J LCD Shield Casev Ass’y AX
10-1
Not Available
– LCD Shield Case —
10-2 PSPAHA454WJZZ J Spacer, x2 AB
To Next Page
