Sharp UP-3300

1 Top cabinet etc.
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
GSTN-2005BHZZ AT
D Tilt stand
2
JKNBZ2411BHZZ AH
C Tilt knob
3
MSPRP2372BHZZ AE
C Tilt spring
4
MLEVF2324BHZZ AG
C Tilt lever
5
LX-BZ6787BHZZ AB
CScrew (3×5)
6
XJSSD30P10000 AA
CScrew (3×10)
7
GCABF7873BHZZ BA
D LCD rear cabinet
8
PGUMM2389BHZZ AE
C LCD cushion
9
MHNG-2324BHZZ AX
C Hinge L
10
XUBSD40P08000 AA
CScrew (4×8)
11
MHNG-2325BHZZ AX
C Hinge R
12
QCNW-2972BHZA AR
N C Flat cable (40P 280mm)
13
QCNW-2995BHZZ AF
C GND wire (LCD angle-Main Chassis)
14
XHBSD30P05000 AA
CScrew (3×5)
15
XEBSD30P08000 AA
CScrew (M3×8)
16
QCNW-2976BHZZ AK
C Inverter cable
17
LANGK7649BHZZ AV
C LCD plate
18
XEPSD30P08000 AA
CScrew (3×8)
19
QCNW-2973BHZZ AS
C Flat cable (30P 0.5mm PITCH)
21
CPWBN2789BH01 BA
E LCD PWB unit
22
QCNW-2996BHZZ AD
C LCD GND wire
23
CPWBN7571BH01 BR
E Touch panel PWB unit
24
GCOVH7167BHZZ AH
D Invertor cover
25
CPWBN2794BH01 BQ
E Inverter PWB unit
26
VVLLM10V33/-1 CS
E LCD (LM10V33)
27
RCORF6709RCZZ AL
C Core
28
PGUMM6731BHZZ AR
C T/P gum B
29
PGUMM6733BHZZ AR
C LCD gum B
30
PGUMM6732BHZZ AS
C LCD gum A
31
HPNLC6839RCZZ BT
D Touch panel
32
PGUMM6734BHZZ AL
C T/P gum C
33
PGUMM6730BHZZ AS
C T/P gum A
34
GCABE7872BHZZ AX
D LCD front cabinet
35
GCOVA7159BHZZ AS
D Side cover
36
LANGK7651BHZZ AL
C Cab angle 2
37
GCOVA7166BHZZ AP
D Tilt cover
38
PSHEG2859BHZZ AV
C Dust sheet
39
XJSSD30P08000 AA
CScrew (3×8)
40
JKNBZ6923BHZZ AP
C Tilt lock
41
GCABB7870BHZZ BB
D Top cabinet
42
GFTAT6927BHZZ AR
D Keyboard lid
43
XBBSD30P08000 AA
CScrew (M3×8)
44
PSHEP2472BHZZ AH
C W sheet 2
45
PSHEP2471BHZZ AH
C W sheet 1
46
LANGK7650BHZZ AH
C Cab angle 1
47
GFTAT6928BHZZ AV
D Printer lid
48
GCOVA7158BHZZ AW
D Rear cover
49
PFILW6979BHZZ AV
D Rear filter
50
RCORF2031SCZZ AN
C Core (SSC-50-12-F)
51
XUPSD40P12000 AA
CScrew (M4×12)(M)
52
LANGT2847BHZZ AP
N C Rear cover angle
53
XEBSD30P06000 AA
CScrew (M3×6)
UP-3300VUP-3300V
– 1 –
