Sharp VC-H965U

Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
72
VC-A565U/H965U
Q968 VS2SA1530ARS1 V 2SA1530AR AC
Q7781 VS2SC3052EF-1 V 2SC3052EF AC
DIODES AND LED’S
D351 VHD1SS119//-1 V 1SS119(VC-H965U) AB
D701 RH-PX0270GEZZ J LED, Cassette LED AC
D706 RH-PX0252GEZZ J LED, Supply Reel Sensor AF
D707 RH-PX0252GEZZ J LED, Takeup Reel Sensor AF
D712 VHD1SS119//-1 V 1SS119 AB
å D901 VHDRL1N4004-1 V RL1N4004 AD
å D902 VHDRL1N4004-1 V RL1N4004 AD
å D903 VHDRL1N4004-1 V RL1N4004 AD
å D904 VHDRL1N4004-1 V RL1N4004 AD
å D905 VHD10ELS4//-1 V 10ELS4 AD
å D907 VHD1SS119//-1 V 1SS119 AB
å D912 RH-EX0601GEZZ J Zener Diode, 3.6V AA
å D913 VHD1SS119//-1 V 1SS119 AB
å D931 VHD10ELS4//-1 V 10ELS4 AD
D932 VHD10ELS4//-1 V 10ELS4 AD
å D933 VHD15DF1FC/1E V 15DF1FC AD
D963 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D972 RH-EX0677GEZZ J Zener Diode, 33.1v AB
å D9334 RH-DX0064GEZZ J DX0064GE AC
å IC901 RH-FX0034CEZZ V PC817 AE
Q701 RH-PX0233GEZZ J LED, Start Sensor AD
Q702 RH-PX0233GEZZ J LED, End Sensor AD
PACKAGED CIRCUITS
X501 RCRSB0204GEZZ J Crystal, CRSB0204GE AG
X701 RCRSB0205GEZZ J Crystal, CRSB0205GE AM
COILS
L101 VP-CF101K0000 V Peaking, 100µHAB
L104 VP-XF100K0000 V Peaking, 10µHAB
L201 VP-XF820K0000 V Peaking, 82µHAB
L253 VP-XF101K0000 V Peaking, 100µHAB
L301 VP-MK101K0000 V Peaking, 100µHAB
L351 VP-MK101K0000 V Peaking, 100µHAB
(VC-H965U)
L503 VP-XF120K0000 V Peaking, 12µHAB
L602 VP-DF221K0000 V Peaking, 220µHAB
å L901 RCiLF0005AJZZ V Coil, CiLF0005AJ AE
å L933 RCiLP0147GEZZ J Coil, 10µHAC
å L934 RCiLP0147GEZZ J Coil, 10µHAC
TRANSFORMERS
T601 RTRNH0098GEZZ J OSC. Transformer AE
(VC-A565U)
T601 RTRNHA001WJZZ V OSC. Transformer AD
(VC-H965U)
å T901 RTRNW0009AJZZ V Transformer AK
CAPACITORS
C102 VCKYCY1HB562K V 5600p 50V Ceramic AA
C103 VCEA9A1CW106M V 10 16V Electrolytic AB
C105 VCEA0A0JW477M V 470 6.3V Electrolytic AC
C106 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C114 VCKYCY1HB221K V 220p 50V Ceramic AA
C144 VCEA9M1HW335M V 3.3 50V Electrolytic AB
(VC-H965U)
C145 VCEA9M1HW335M V 3.3 50V Electrolytic AB
(VC-H965U)
C146 VCEA9M1HW105M V 1 50V Electrolytic AB
(VC-H965U)
C148 VCKYCY1CF104Z V 0.1 16V Ceramic AA
(VC-H965U)
C160 VCEA9M1HW225M V 2.2 50V Electrolytic AB
(VC-H965U)
C162 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C163 VCEA9M1HW475M V 4.7 50V Electrolytic AB
(VC-H965U)
C164 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C165 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C166 VCKYCY1EB223K V 0.022 25V Ceramic AA
(VC-H965U)
C167 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C168 VCEA9M1CW106M V 10 16V Electrolytic AB
(VC-H965U)
C169 VCEA9M1HW105M V 1 50V Electrolytic AB
(VC-H965U)
C201 VCEA9M0JW476M V 47 6.3V Electrolytic AB
C202 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C203 VCCCCY1HH151J V 150p 50V Ceramic AA
C204 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C205 VCCCCY1HH560J V 56p 50V Ceramic AA
C206 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C207 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C208 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C209 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C210 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C211 VCEA9M1HW335M V 3.3 50V Electrolytic AB
C212 VCEA9M1CW106M V 10 16V Electrolytic AB
C213 VCEA9M1HW225M V 2.2 50V Electrolytic AB
C214 VCEA9M1HW105M V 1 50V Electrolytic AB
C215 VCEA9M1HW105M V 1 50V Electrolytic AB
C216 VCEA9M1HW105M V 1 50V Electrolytic AB
C217 VCEA9M0JW476M V 47 6.3V Electrolytic AB
C218 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C219 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C220 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C221 VCEA9M1CW106M V 10 16V Electrolytic AB
C223 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C227 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C252 VCEA0A0JW337M V 330 6.3V Electrolytic AC
C301 VCEA9M0JW476M V 47 6.3V Electrolytic AB
C302 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C303 VCKYCY1HB102K V 1000p 50V Ceramic AA
C304 VCKYCY1HB562K V 5600p 50V Ceramic AA
C305 VCKYCY1HB562K V 5600p 50V Ceramic AA
C306 VCKYCY1HB102K V 1000p 50V Ceramic AA
C307 VCKYCY1HB102K V 1000p 50V Ceramic AA
C308 VCKYCY1HB562K V 5600p 50V Ceramic AA
C309 VCKYCY1HB562K V 5600p 50V Ceramic AA
C310 VCKYCY1HB102K V 1000p 50V Ceramic AA
C311 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C312 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C319 VCCCCY1HH100D V 10p 50V Ceramic AA
C320 VCCCCY1HH100D V 10p 50V Ceramic AA
C351 VCEA9M0JW476M V 47 6.3V Electrolytic AB
(VC-H965U)
C352 VCKYCY1CF104Z V 0.1 16V Ceramic AA
(VC-H965U)
C353 VCKYCY1HF103Z V 0.01 50V Ceramic AA
(VC-H965U)
C354 VCKYCY1HF103Z V 0.01 50V Ceramic AA
(VC-H965U)
C356 VCCCCY1HH101J V 100p 50V Ceramic AA
(VC-H965U)
C357 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C358 VCKYCY1CB104K V 0.1 16V Ceramic AB
(VC-H965U)
C501 VCEA9M0JW107M V 100 6.3V Electrolytic AB
C502 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C503 VCKYCY1HB472K V 4700p 50V Ceramic AA
C504 VCEA9M1HW225M V 2.2 50V Electrolytic AB
C505 VCKYCY1EB223K V 0.022 25V Ceramic AA
C506 VCEA9M1HW474M V 0.47 50V Electrolytic AB
C507 VCKYCY1CF104Z V 0.1 16V Ceramic AA
C508 VCEA9M1HW475M V 4.7 50V Electrolytic AB
C509 VCKYD41CY103N V 0.01 16V Ceramic AA
C511 VCKYCY1HF103Z V 0.01 50V Ceramic AA
(VC-H965U)
C512 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C513 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C514 VCKYCY1HF103Z V 0.01 50V Ceramic AA
C515 VCKYCY1HB331K V 330p 50V Ceramic AA
C517 VCEA9M1HW335M V 3.3 50V Electrolytic AB
C518 VCKYCY1HF333Z V 0.033 50V Ceramic AA
