3. PART NAMES AND FUNCTION
Front view
When the cassette compartment door is open
Terminal cover
Microphone
Zoom lens
AUDIO/VIDEO jack
DC IN jack
Lens hood
Cassette holder
Shoulder strap loop Lithium battery holder
Cassette compartment door release
Cassette compartment door
Speaker
Rear view
Bottom view
For details on the use of each control.
Power Zoom Wide angle/ Telephoto control VOLume control
Shoulder strap loop
FADE button
Hand strap
RECord START/STOP button
Battery compartment door
CHARGE indicator
MENU button
Remote sensor
LCD monitor screen
Tripod socket
Power switch (CAMERA/VCR select switch)
DISPLAY button
Operation buttons
Battery compartment door release
