107
VL-E990E
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-A10U/UC/UA/UW/T/K
VL-AH30U/UC/T
5 DFTAC1304LM01 VCR Lid Service
(A10U/UC/UA/UW/T/K)
5 DFTAC1302LM01 VCR Lid Service AS
(AH30U/UC/T)
5-2 HDECP0057TASA VCR Lid Decoration Plate
(A10U/UC/UA/UW/T/K)
5-2 HDECP0055TASA VCR Lid Decoration Plate AE
(AH30U/UC/T)
5-3 LANGK0533TAFF VCR Lid Spring Angle AC
5-4 LANGK0400TAFW Eject Fitting AD
5-5 MSPRD0070TAFJ VCR Lid Spring
6 DCOVA1647LM01 Camera Side Cover Service AR
(A10U/AH30U)
6 DCOVA1647LM02 Camera Side Cover Service
(A10UC/AH30UC)
6 DCOVA1647LM03 Camera Side Cover Service
(A10UA/UW)
6 DCOVA1647LM04 Camera Side Cover Service
(A10T/AH30T)
6 DCOVA1647LM05 Camera Side Cover Service
(A10K)
6-2 NSFTZ0049TAFW Battery Lid Axle AC
6-3 MSPRD0050TAFJ Battery Lid Open/Close AC
Spring
6-4 TLABH0264TAZZ Recycling Label AB
(A10U/AH30U)
6-4 TLABH0317TAZZ Recycling Label AC
(A10UC/AH30UC)
6-5 GFTAB1066TAKA Battery Lid AE
6-6 HDECP0045TASA Battery Decoration Plate AC
(A10U/UC/UA/UW/AH30U/UC)
6-6 HDECP0047TASA Battery Decoration Plate AC
(A10T/AH30T)
6-6 HDECP0070TASA Battery Decoration Plate
(A10K)
6-7 MSPRC0102TAFJ Battery Lock Lever Spring AA
6-8 MLEVP0030TASA Battery Lid Open/Close AC
Lever
6-9 LHLDZ1532TAZZ Battery Lock Holder AC
6-10 MLEVP0044TASA Battery Lock Lever AC
6-11 MSPRC0101TAFJ Battery Push-out Spring AD
6-12 LHLDZ1445TAZZ Lens Holder AD
6-13 LANGK0398TA00 Battery Lid Angle Fitting AH
6-14 UBNDT0122TAZZ Hand Strap AH
7 DCOVA1650LM01 Tilt Service AP
7-2 PSPAZ0190TAZZ Tilt Spacer AE
7-3 GCOVA1537TAKA Tilt Frame V AL
7-4 PSPAZ0189TAZZ Rotation Spacer AD
7-5 LANGH0071TAFW Stopper Fitting AD
8 LHLDZ1533TAZZ LCD Holder AH
9 PSHEP0044TAZZ Prism Sheet AG
10 PSHEP0045TAZZ Diffusion Sheet AD
11 PGiDM0037TAZZ Light Guide Plate AG
12 PMiR-0021TAZZ Reflection Sheet AC
å 13 CLMPV0048RM05 Lamp Inverter Unit
14 CPNLC0047RM04 LCD Panel
15 PZETV0343TAZZ LCD Lead Sheet AA
17 TLABM2063TAZZ Model Label(AH30UC)
17 TLABM2067TAZZ Model Label(AH30U) AD
17 TLABM2072TAZZ Model Label(A10U)
17 TLABM2073TAZZ Model Label(A10UC)
17 TLABM2079TAZZ Model Label(A10UW)
17 TLABM2080TAZZ Model Label(A10UA)
17 TLABM2083TAZZ Model Label(AH30T)
17 TLABM2103TAZZ Model Label(A10T)
17 TLABM2109TAZZ Model Label(A10K)
18 CLNSA0127TA01 Lens Unit BS
19 GFTAC1241TASA Cassette Compartment AD
Cover
20 DUNTK2949QA00 VCR Unit —
(AH30U/UC)
20 DUNTK2949QA03 VCR Unit —
(A10U/UC/UA/UW)
20 DUNTK2949QA05 VCR Unit(A10T) —
20 DUNTK2949QA06 VCR Unit(AH30T) —
20 DUNTK2949QA12 VCR Unit(A10K) —
21 DUNTK2934QA00 CAMERA Unit —
22 QPWBH2937TAZZ Tilt FPC
23 LHLDW1038TA00 FPC Holder AC
24 RUNTK0353TAZZ VCR Operation Unit AS
(A10U/UC/UA/UW/K/AH30U/UC)
24 RUNTK0369TAZZ VCR Operation Unit
(A10T/AH30T)
25 QTANZ0146TAZZ Battery Terminal Unit AK
26 QSW-Z0285TAZZ Power/Zoom Unit AR
27 LHLDZ1452TAZZ Power Lock Holder AC
28 MSPRC0083TAFJ Power Lock Spring AA
29 JBTN-0277TASA Power Button AD
(A10U/UC/UA/UW/T/K)
29 JBTN-0277TASB Power Button AF
(AH30U/UC/T)
30 LHLDZ1451TAZZ Power Holder AC
31 JKNBP0152TASA Power Knob AD
32 JKNBP0153TASA Zoom Knob AD
(A10U/UC/UA/UW/T/K)
32 JKNBP0153TASB Zoom Knob(AH30U/UC/T) AF
33 LHLDZ1453TASA Zoom Knob Holder AD
34 JKNBP0154TASA Open Knob AC
35 PSPAZ0191TAZZ Microphone Spacer AA
36 RMiCC0090TAZZ Microphone AN
37 MSPRT0034TAFJ Lid Lock Spring AC
38 LHLDZ1454TA00 Lid Lock AD
39 NSFTZ0084TAFW VCR Lid Shaft AD
40 PSPAZ0318TAZZ Microphone Ware Spacer
41 LHLDZ1450TAZZ Speaker Holder AC
42 VSP0020P-A7WN Speaker
43 PSPAG0103TAZZ Speaker Spacer AC
46 DCOVA3056LM01 Speaker Cover AE
47 PSPAH0031TAZZ Wire Holder
48 QSW-Z0342TAZZ Turn/Eject SW
49 MLEVP0031TAZZ Eject Lever AC
50 LANGK0399TAZZ Tripod Angle
51 PSHEP0160TAZZ Microphone Lead Sheet AC
52 RUNTK0354TAZZ Lithium Unit AF
54 GCOVA1651TAKA Microphone Cover
55 QPWBH2815TAZZ CCD FPC AE
56 CCOVA1652LM01 AV Unit Cover Service AD
(A10U/UC/UA/UW/K/AH30U/UC)
56 CCOVA1652LM03 AV Unit Cover Service
(A10T/AH30T)
56-2 HiNDP0214TASA Video indication Panel
(A10U/UC/UA/UW/K/AH30U/UC)
56-2 HiNDP0223TASA Video Indication Panel
(A10T/AH30T)
57 GCOVA1649TASA Adjust Hole Cover
58 RUNTK0352TAZZ AV Jack Unit AS
59 RUNTK0356TAZZ 6-cell Detection Unit
60 PSHEP0159TAZZ Wire Fix Sheet AB
61 TLABZ0501TAZZ Label(A10K)
62 PSPAZ0331TAZZ Microphone Spacer
a LX-HZ0018TAFN M2x6 Tapping, Silver AA
b LX-HZ0018TAFF M2x6 Tapping, Black AA
c LX-HZ0045TAFN M2x4 Tapping, Silver AA
d XiPSF20P04000 M2x4 Small Screw, Black AA
Zinc Plating
e LX-BZ0191TAFD M2 Special Screw AC
f XiPSD20P03000 M2x3 Screw AA
g LX-UZ0016TAFD M2x5 Special Screw AA
h LX-BZ0200TAFD M2x7 Special Screw AB
i XiPSN20P04000 M2x4 Small Screw, Silver AA
k LX-HZ0063TAFC M1.7x6 Tapping, Silver AA
