Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
10-1
VL-H860S/H/VL-H870S
VL-H890S/VL-H94E
VL-H96E/VL-H960E
VL-H860S/H/VL-H870S
VL-H890S/VL-H94E
VL-H96E/VL-H960E
IC800 VHiiR3Y29AM-1 IR3Y29AM, LCD Decoder AV
IC900 VHiMB3825A/-1 MB3825A, Power Control AR
IC(Master)
IC901 VHiMB3788FV-1 MB3788FV, Power Control AM
IC(Slave)
IC902 VHiBU4051FV-1 BU4051FV, Multiplexer AF
IC1401 VHiCXA2083R-1 CXA2083R, IN PUT/ AU
OUT PUT Process
IC1602 VHiBA7785FS-1 BA7785FS, Headphone/ AN
Speaker Amp.
IC1800 VHiNJM4565V-1 NJM4565V, Current Detecter AF
IC1801 VHiNJM2107F-1 NJM2107F, AFC LPE AE
IC1802 VHiLZ9GH16/-1 LZ9GH16, LCD Controler AP
(H860S/H/H870S/H94E/EW/EX/
H96E/EW/EX)
IC1802 VHiLZ9GH17/-1 LZ9GH17, LCD Controler AP
(H890S/H960E/EW)
IC2401 VHiM52358VP-1 M52358VP, PAL Jog AS
IC2701 VHiNJM2904M-1 NJM2904M, L.P.F. Amp. AE
IC2702 VHiCXA1814N-1 CXA1814N, ATF IC AQ
IC2901 VHiMM1433BV-1 MM1433BV, Charge AQ
Control IC
IC3701 VHiBU2092FV-1 BU2092FV AG
IC3702 VHiBU2092FV-1 BU2092FV AG
IC4401 VHiCXL5517N-1 CXL5517N, CCD Delay Line AM
IC4701 VHiMB88344F-1 MB88344F, D/A Converter AV
IC4702 VHiMB8346BV-1 MB88346BV, D/A ConverterAN
IC5401 VHiCXL5517N-1 CXL5517N, CCD Delay Line AM
IC6601 VHiLA7471M/-1 LA7471M, Mic Amp. AN
IC7451 VHiCXA1211M-1 CXA1211M, VCA AH
IC8301 VHiM52374VP-1 M52374VP, COS-EQ AK
TRANSISTORS
Q401 VSRN1903///-1 RN1903 AC
Q402 VSRN1903///-1 RN1903 AC
Q403 VSRT1N441U/-1 RT1N441U AB
Q404 VSRT1N241U/-1 RT1N241U AB
Q406 VS2SA1989R/-1 2SA1989R AB
Q407 VSRN2704///-1 RN2704 AC
Q408 VSRN2704///-1 RN2704 AC
Q409 VSRN1703///-1 RN1703 AC
Q410 VSRN1703///-1 RN1703 AC
Q411 VS2SA1989R/-1 2SA1989R AB
Q413 VSRT1N441U/-1 RT1N441U AB
Q415 VSHN1B01FU/-1 HN1B01FU AC
Q416 VSRT1N441U/-1 RT1N441U AB
Q451 VS2SC5383F/-1 2SC5383F AB
Q452 VSHN2C01FU/-1 HN2C01FU AC
Q453 VSRN1910///-1 RN1910 AC
Q601 VSFMG12////-1 FMG12 AD
Q603 VSRN4984///-1 RN4984 AC
Q604 VS2SC5383F/-1 2SC5383F AB
Q605 VSRT1N441U/-1 RT1N441U AB
Q606 VS2SA1989R/-1 2SA1989R AB
Q607 VSHN1B01FU/-1 HN1B01FU AC
Q701 VSRN4983///-1 RN4983 AC
Q702 VSRN1904///-1 RN1904 AC
Q703 VSRT1N241U/-1 RT1N241U AB
Q704 VSRN1904///-1 RN1904 AC
Q705 VSRN1904///-1 RN1904 AC
Q706 VSHN1C01FU/-1 HN1C01FU AC
Q707 VSHN2C01FU/-1 HN2C01FU AC
Q708 VSRN1904///-1 RN1904 AC
Q709 VSRN1904///-1 RN1904 AC
Q710 VSRT1N241U/-1 RT1N241U AB
(H860S/H/H94E/EW/EX)
Q712 VSRN1904///-1 RN1904 AC
(H860S/H/H94E/EW/EX)
Q713 VSRN1904///-1 RN1904 AC
(H860S/H/H94E/EW/EX)
Q714 VSRN1904///-1 RN1904 AC
(H860S/H/H94E/EW/EX)
Q715 VSRT1N241U/-1 RT1N241U AB
(H870S/H890S/H96E/EW/EX/
H960E/EW)
10.REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
" HOW TO ORDER REPLACEMENT PARTS "
★MARK : SPARE PARTS-DELIVERY SECTION:ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK2887QA00 VCR Unit(VL-H860S) —
DUNTK2887QA01 VCR Unit(VL-H860H) —
DUNTK2887QA02 VCR Unit(VL-H94E/EW/EX)—
DUNTK2887QA03 VCR Unit(VL-H870S) —
DUNTK2887QA05 VCR Unit(VL-H96E/EW/EX)—
DUNTK2887QA06 VCR Unit(VL-H890S) —
DUNTK2887QA08 VCR Unit(VL-H960E/EW) —
DUNTK2890QA00 CAMERA1 Unit —
DUNTK2893QA00 CAMERA2 Unit —
DUNTK2895PM01 CCD Unit —
RAMP-0031TAN1 HEAD AMP Unit —
DUNTK2887QA00(VL-H860S)
DUNTK2887QA01(VL-H860H)
DUNTK2887QA02(VL-H94E/EW/EX)
DUNTK2887QA03(VL-H870S)
DUNTK2887QA05(VL-H96E/EW/EX)
DUNTK2887QA06(VL-H890S)
DUNTK2887QA08(VL-H960E/EW)
VCR UNIT
INTEGRATED CIRCUITS
å CP901 VHiCCP2E30/-1 CCP2E30, 1.25A 72V AD
å CP902 VHiCCP2E30/-1 CCP2E30, 1.25A 72V AD
å CP903 VHiCCP2E30/-1 CCP2E30, 1.25A 72V AD
IC401 VHiCXA2085R-1 CXA2085R, Luminance AX
Process
IC601 VHiCXA1737R-1 CXA1737R, AFM Signal AU
Process
IC602 VHiTC4W66U/-1 TC4W66U, I/O SW AF
IC701 VHiRH5RE33A-1 RH5RE33A, 3.3V REG AE
IC702 VHiRN5VD29A-1 RN5VD29A, 2.9V DET AE
IC703 VHiS24C02A/-1 S24C02A AK
IC704 RH-iX0672TAZZ IX0672TA, System/Servo AT
Control(H870S/H890S/H96E/EW/
EX/H960E/EW)
IC704 RH-iX0674TAZZ IX0674TA, System/Servo AT
Control(H860S/H/H94E/EW/EX)
IC705 RH-iX0667TAZZ IX0667TA, OSD AQ
IC706 VHiRS5C313/-1 RS5C313, Clock AL
