WF-2100W
– 1 –
INTEGRATED CIRCUITS
IC101 VHILA1186N/-1 J AE FM Front End,LA1186N
IC102 VHILA1805//-1 J AM FM/AM IF MPX.,LA1805
IC201 VHITA8189N/-1 J AM Record/Playback Amp.,TA8189N
IC202 92L2351-177001 J Mic Amp.,BA15218F
IC301 92L2301-370001 J Graphic Equalizer,BA3822LS
IC302,303 VHILB1403N/-1 J AG Meter Driver,LB1403N
IC401 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC402 VHILA4663//-1 J AQ Power Amp.,LA4663
IC403 92L2301-240001 J Voltage Regulator,L7808CV
IC404 92L2301-237003 J Voltage Regulator,L7809CV
TRANSISTORS
Q201,202 92L2123-009001 J Silicon,NPN,2SC2412 KR
Q203 VS2SC945AP/-1 J AB Silicon,NPN,2SC945 AP
Q204 VSKTC3875GR-1 J AB Silicon,NPN,KTC3875 GR
Q205 92L2103-109001 J AC Silicon,NPN,3DA8050
Q206 VSKTC3875GR-1 J AB Silicon,NPN,KTC3875 GR
Q207 92L2101-025001 J AC Silicon,PNP,SS8550
Q208 92L2103-054003 J Silicon,NPN,SS8050
Q209,210 VS2SC945AP/-1 J AB Silicon,NPN,2SC945 AP
Q212 VSKTC3875GR-1 J AB Silicon,NPN,KTC3875 GR
Q213 92L2101-025001 J AC Silicon,PNP,SS8550
Q216~221 VSKTC3875GR-1 J AB Silicon,NPN,KTC3875 GR
Q301,302 92L2123-017001 J Silicon,NPN,KTC3875 GR
Q504 92L2101-025001 J AC Silicon,PNP,SS8550
Q505,506 92L2123-009001 J Silicon,NPN,2SC2412 KR
DIODES
D101~103 VHD1N4148//-1 J AA Silicon,1N4148
D201~203 VHD1N4148//-1 J AA Silicon,1N4148
D205 VHD1N4148//-1 J AA Silicon,1N4148
D207 VHD1N4148//-1 J AA Silicon,1N4148
D209 VHD1N4148//-1 J AA Silicon,1N4148
D211~219 VHD1N4148//-1 J AA Silicon,1N4148
D401 VHD1N4148//-1 J AA Silicon,1N4148
D501 VHD1N4148//-1 J AA Silicon,1N4148
D503,504 VHD1N4148//-1 J AA Silicon,1N4148
D506 VHD1N4148//-1 J AA Silicon,1N4148
D508~511 VHD1N4148//-1 J AA Silicon,1N4148
D601~604 92L2501-089001 J Silicon,1N5402
LD301~312 92L2509-067001 J LED,Red,L01-224HD
LD313 92L2509-080001 J LED,Green,
LD314 92L2509-067001 J LED,Red,L01-224HD
FILTERS
BP101 92L4401-008001 J AG Band Pass Filter
CF101 92L4403-060001 J FM IF
CF102 92L4403-061002 J AM IF
TRANSFORMERS
T101 92L1111-025001 J AE SW1 Antenna
T102 92L1104-114001 J SW2 Antenna
T103 92L1104-099001 J MW OSC.
T104 92L1104-090001 J AD SW1 OSC.
T105 92L1104-089001 J AD SW2 OSC.
T106 92L1104-100001 J FM Detection
T107 92L1104-097001 J AM IF
T108 92L1104-038001 J AE FM IF
T201 92L1104-105008 J Bias OSC.
1 T601 92L5102-126001 J Power
COILS
L101 92L1104-098001 J FM OSC.
L102 92L1107-009001 J AB FM Tracking
L103 92L7602-006001 J MW Bar Antenna
L201,202 92L1101-161001 J 47 mH
L203,204 92L1101-150038 J 2.7 mH
L501 92L1101-003017 J 47 µH
VARIABLE RESISTORS
VR101 92L1701-060001 J 100 kohm (B),Semi-VR
[Fine Tuning]
VR102 92L1601-001001 J AD 10 kohm (B),Semi-VR [VCO]
VR301 92L1702-008004 J 50 kohms (B)×2,Semi-VR
[X-Bass]
VR302 92L1702-008003 J 100 kohm (B)×2,Semi-VR
[Graphic Equalizer]
VR303 92L1702-008002 J 100 kohm (B)×2,Semi-VR
[Graphic Equalizer]
VR304 92L1702-008001 J 50 kohms (B)×2,Semi-VR
[Graphic Equalizer]
VR305 92L1702-008005 J 100 kohm (B)×2,Semi-VR
[Graphic Equalizer]
VR401 92L1701-059002 J 50 kohms (B)×2,Semi-VR
[Volume]
VR501 92L1601-001007 J 500 ohms (B),Semi-VR
[Tape Speed]
VARIABLE CAPACITORS
CT101~104 92L1341-007001 J AE Trimmer,10 pF
VC1~4 92L1340-003001 J AQ Variable Capacitor with Trimmer
(TC1~4)
VD101 92L2507-001001 J AD Variable Capacitanse,1S2638
CAPACITORS
C101,102 VCKYPA1HB102K J AA 0.001 µF,50V
C103 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C104 VCKYPA1HB102K J AA 0.001 µF,50V
C105 VCCCPU1HH8R0C J AA 8 pF (CH),50V
C106,107 VCCCPU1HH150J J AA 15 pF (CH),50V
C108 VCCCPU1HH200J J AA 20 pF (CH),50V
C109 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C110 VCKZPA1HF223Z J AA 0.022 µF,50V
C111 92L1321-001095 J 330 pF (CH),50V
C112 VCCCPU1HH300J J AA 30 pF (CH),50V
C113 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C114 VCQYKA1HM472J J AA 0.0047 µF,50V,Mylar
C115 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C116~118 VCKYTV1EF223Z J AA 0.022 µF,25V
C119 VCKZPA1HF223Z J AA 0.022 µF,50V
C120 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C121 VCKZPA1HF223Z J AA 0.022 µF,50V
C122 VCKYTV1EF223Z J AA 0.022 µF,25V
C123 VCKZPA1HF223Z J AA 0.022 µF,50V
C124 VCEAZA1CW226M J AC 22 µF,16V,Electrolytic
C125,126 VCKYTV1HB822K J AA 0.0082 µF,50V
C127~129 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C130 VCKZPA1HF223Z J AA 0.022 µF,50V
C131 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C132,133 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C134 VCCSPU1HL471J J AB 470 pF,50V
C135 VCQYKA1HM822K J AA 0.0082 µF,50V,Mylar
C136 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C137 VCKZPA1HF223Z J AA 0.022 µF,50V
C138 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C139 VCKZPA1HF223Z J AA 0.022 µF,50V
C140 VCTYPA1EF104Z J AA 0.1 µF,25V
C142 92L1321-001095 J 330 pF (CH),50V
C143 VCCCPU1HH150J J AA 15 pF (CH),50V
C144 VCCCPU1HH5R0C J AA 5 pF (CH),50V
C201,202 VCKYTV1HB471K J AA 470 pF,50V
C203~206 VCKYTV1HB221K J AA 220 pF,50V
C207,208 VCEAZA1CW226M J AC 22 µF,16V,Electrolytic
C209,210 VCQYKA1HM333J J AB 0.033 µF,50V,Mylar
C213~216 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C217,218 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C219,220 VCKYTV1HB102K J AA 0.001 µF,50V
C221~223 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C224 VCEAZA1CW337M J AC 330 µF,16V,Electrolytic
C225 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C226 VCKYTV1HB152K J AA 0.0015 µF,50V
C227 92L1323-014021 J 82 pF,50V
C228 VCKYTV1HB152K J AA 0.0015 µF,50V
C229 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C230 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C231,232 VCKYTV1HB821K J AA 820 pF,50V
