Sharp WF-2100W User Manual

NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
WF-2100W
C233,234 VCKYTV1HB151K J AC 150 pF,50V
C235 VCCCPU1HH181J J AA 180 pF (CH),50V
C236 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C237 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C238 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C239 VCQYKA1HM102K J AA 0.001 µF,50V,Mylar
C240 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C241 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C242 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C243 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C244 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C245 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C246 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C247 VCKYTV1HB151K J AC 150 pF,50V
C248 VCKYTV1HB101K J AA 100 pF,50V
C249~251 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C252 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C253 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C254~256 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C257 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C258,259 VCKYTV1HB221K J AA 220 pF,50V
C260 VCKYTV1HB151K J AC 150 pF,50V
C261 92L1323-014021 J 82 pF,50V
C262,263 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C267,268 VCCSTV1HL331J J AA 330 pF,50V
C269 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C270,271 VCKYTV1HB153K J AA 0.015 µF,50V
C280 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C281 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C288 VCEAZA1CW337M J AC 330 µF,16V,Electrolytic
C301,302 RC-EZD225AF1H J AB 2.2 µF,50V,Electrolytic
C303,304 VCKYTV1HF223Z J AA 0.022 µF,50V
C305~307 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C308 VCKYTV1HF223Z J AA 0.022 µF,50V
C309 VCKYTV1HB183K J AA 0.018 µF,50V
C310 VCCCTV1HH821J J AA 820 pF (CH),50V
C311 RC-EZD334AF1H J AB 0.33 µF,50V,Electrolytic
C312 VCKYTV1HB562K J AA 0.0056 µF,50V
C313 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C314 VCKYTV1HB332K J AA 0.0033 µF,50V
C315 VCKYTV1HF104Z J AA 0.1 µF,50V
C316 VCKYTV1HB332K J AA 0.0033 µF,50V
C317 RC-EZD334AF1H J AB 0.33 µF,50V,Electrolytic
C318 VCKYTV1HB562K J AA 0.0056 µF,50V
C319 VCKYTV1HB183K J AA 0.018 µF,50V
C320 VCCCTV1HH821J J AA 820 pF (CH),50V
C321 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C322 VCKYTV1HF223Z J AA 0.022 µF,50V
C323,324 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
C325 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C326 VCKYTV1HB102K J AA 0.001 µF,50V
C328~330 RC-EZD106AF1C J AB 10 µF,16V,Electrolytic
C331 VCKYTV1HB102K J AA 0.001 µF,50V
C333 RC-EZD106AF1C J AB 10 µF,16V,Electrolytic
C334 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C335 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C401,402 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C403,404 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C405,406 VCKYTV1HB332K J AA 0.0033 µF,50V
C407,408 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
C409,410 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C411 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C412 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C413,414 VCKYTV1HB102K J AA 0.001 µF,50V
C415,416 VCQYKA1HM154K J AB 0.15 µF,50V,Mylar
C417,418 VCKYTV1HB102K J AA 0.001 µF,50V
C419,420 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C422 VCKZPA1HF223Z J AA 0.022 µF,50V
C424 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C425~428 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C429,430 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C501 VCEAZA1HW336M J AC 33 µF,50V,Electrolytic
C502 VCTYPA1EF104Z J AA 0.1 µF,25V
C505,506 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C508 VCKYTV1EF223Z J AA 0.022 µF,25V
C509 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C511,512 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C514,515 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C516 VCTYPA1EF104Z J AA 0.1 µF,25V
C517,518 VCQYKA1HM272K J AA 0.0027 µF,50V,Mylar
C601~604 VCKZPA1HF223Z J AA 0.022 µF,50V
RESISTORS
R101 VRD-ST2CD101J J AA 100 ohm,1/6W
R102 VRD-ST2CD330J J AA 33 ohms,1/6W
R103 VRD-ST2CD224J J AA 220 kohms,1/6W
R104 VRD-ST2CD824J J AA 820 kohms,1/6W
R105 VRD-ST2CD101J J AA 100 ohm,1/6W
R106 VRD-ST2CD104J J AA 100 kohm,1/6W
R107 VRS-TV2AB104J J AA 100 kohm,1/10W
R108 VRS-TV2AB103J J AA 10 kohm,1/10W
R109 VRD-ST2CD223J J AA 22 kohms,1/6W
R110~112 VRD-ST2CD470J J AA 47 ohms,1/6W
R113 VRD-ST2CD273J J AA 27 kohms,1/6W
R114 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R115 VRD-ST2CD273J J AA 27 kohms,1/6W
R116 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R117 VRD-ST2CD100J J AA 10 ohm,1/6W
R118 VRD-ST2CD104J J AA 100 kohm,1/6W
R119 VRD-ST2CD153J J AA 15 kohms,1/6W
R120 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R121 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R122 VRD-ST2CD100J J AA 10 ohm,1/6W
R123 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R125 VRS-TV2AB104J J AA 100 kohm,1/10W
R126 VRD-ST2EE101J J AA 100 ohm,1/4W
R128 VRS-TV2AB333J J AA 33 kohms,1/10W
R129 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R131 VRD-ST2CD103J J AA 10 kohm,1/6W
R200 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R201,202 VRS-TV2AB470J J AA 47 ohms,1/10W
R203,204 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R205,206 VRD-ST2CD184J J AA 180 kohms,1/6W
R207,208 VRS-TV2AB562J J AA 5.6 kohms,1/10W
R209,210 VRS-TV2AB184J J AA 180 kohms,1/10W
R211,212 VRD-ST2CD102J J AA 1 kohm,1/6W
R213 VRS-TV2AB474J J AA 470 kohms,1/10W
R214 VRD-ST2CD474J J AA 470 kohms,1/6W
R215,216 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R217 VRS-TV2AB104J J AA 100 kohm,1/10W
R218 VRD-ST2CD104J J AA 100 kohm,1/6W
R219 VRS-TV2AB123J J AA 12 kohms,1/10W
R220 VRS-TV2AB103J J AA 10 kohm,1/10W
R221 VRD-ST2CD105J J AA 1 Mohm,1/6W
R222,223 VRD-ST2CD123J J AA 12 kohms,1/6W
R224,225 VRD-ST2CD473J J AA 47 kohms,1/6W
R226,227 VRD-ST2CD103J J AA 10 kohm,1/6W
R228 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R229 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R230 VRS-TV2AB103J J AA 10 kohm,1/10W
R231 VRD-ST2CD271J J AA 270 ohms,1/6W
R232 VRD-ST2CD103J J AA 10 kohm,1/6W
R233 VRD-ST2CD271J J AA 270 ohms,1/6W
R234,235 VRS-TV2AB153J J AA 15 kohms,1/10W
R236,237 VRS-TV2AB473J J AA 47 kohms,1/10W
R238 VRD-ST2CD333J J AA 33 kohms,1/6W
R239 VRD-ST2CD100J J AA 10 ohm,1/6W
R240 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R241 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R242 VRS-TV2AB561J J AA 560 ohms,1/10W
R243 VRD-ST2CD103J J AA 10 kohm,1/6W
R244 VRS-TV2AB391J J AA 390 ohms,1/10W
R245 VRS-TV2AB103J J AA 10 kohm,1/10W
R247 VRS-TV2AB391J J AA 390 ohms,1/10W
R248 VRS-TV2AB271J J AA 270 ohms,1/10W
R249 VRS-TV2AB333J J AA 33 kohms,1/10W
R250 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R251 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R252 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R253 VRS-TV2AB223J J AA 22 kohms,1/10W
R254 VRD-ST2CD103J J AA 10 kohm,1/6W
R255 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R256 VRS-TV2AB223J J AA 22 kohms,1/10W
R257 VRD-ST2CD151J J AA 150 ohms,1/6W
R258 VRD-ST2CD561J J AA 560 ohms,1/6W
R259 VRS-TV2AB221J J AA 220 ohms,1/10W
R260 VRD-ST2CD103J J AA 10 kohm,1/6W
R261,262 VRD-ST2CD183J J AA 18 kohms,1/6W
R263,264 VRD-ST2CD473J J AA 47 kohms,1/6W
R265,266 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R267,268 VRS-TV2AB334J J AA 330 kohms,1/10W
R269,270 VRD-ST2CD392J J AA 3.9 kohms,1/6W
– 2 –

Sharp WF-2100W Specifications

General

Brand	Sharp
Model	WF-2100W
Category	Portable Stereo System
Language	English
