PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
WF-2100W
R271 VRS-TV2AB102J J AA 1 kohm,1/10W
R272 VRS-TV2AB105J J AA 1 Mohm,1/10W
R273 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R274 VRS-TV2AB103J J AA 10 kohm,1/10W
R275 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R276 VRD-ST2CD102J J AA 1 kohm,1/6W
R277 VRD-ST2CD333J J AA 33 kohms,1/6W
R278 VRD-ST2CD102J J AA 1 kohm,1/6W
R279 VRD-ST2CD151J J AA 150 ohms,1/6W
R280 VRS-TV2AB563J J AA 56 kohms,1/10W
R281 VRS-TV2AB103J J AA 10 kohm,1/10W
R282,283 VRD-ST2CD103J J AA 10 kohm,1/6W
R284 VRD-ST2CD473J J AA 47 kohms,1/6W
R285 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R285 VRS-TV2AB223J J AA 22 kohms,1/10W
R286 VRD-ST2CD473J J AA 47 kohms,1/6W
R287 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R288,289 VRD-ST2CD102J J AA 1 kohm,1/6W
R290 VRS-TV2AB103J J AA 10 kohm,1/10W
R292 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R293,294 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R295 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R296,297 VRS-TV2AB102J J AA 1 kohm,1/10W
R298,299 VRD-ST2CD103J J AA 10 kohm,1/6W
R301 VRS-TV2AB102J J AA 1 kohm,1/10W
R302 VRD-ST2CD103J J AA 10 kohm,1/6W
R303~306 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R307 VRD-ST2EE221J J AA 220 ohms,1/4W
R308~310 VRD-ST2CD102J J AA 1 kohm,1/6W
R311,312 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R313 VRD-ST2CD103J J AA 10 kohm,1/6W
R314 VRD-ST2CD121J J AA 120 ohms,1/6W
R315 VRS-TV2AB123J J AA 12 kohms,1/10W
R316 VRS-TV2AB103J J AA 10 kohm,1/10W
R317,318 VRD-ST2CD102J J AA 1 kohm,1/6W
R319 VRD-ST2CD331J J AA 330 ohms,1/6W
R320,321 VRS-TV2AB102J J AA 1 kohm,1/10W
R322 VRD-ST2CD123J J AA 12 kohms,1/6W
R323 VRS-TV2AB103J J AA 10 kohm,1/10W
R324~328 VRS-TV2AB102J J AA 1 kohm,1/10W
R329 VRD-ST2CD121J J AA 120 ohms,1/6W
R330,331 VRD-ST2CD184J J AA 180 kohms,1/6W
R333 VRD-ST2CD102J J AA 1 kohm,1/6W
R334~336 VRS-TV2AB102J J AA 1 kohm,1/10W
R401,402 VRS-TV2AB104J J AA 100 kohm,1/10W
R403 VRD-ST2CD103J J AA 10 kohm,1/6W
R404 VRS-TV2AB103J J AA 10 kohm,1/10W
R405 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R406 VRS-TV2AB272J J AA 2.7 kohms,1/10W
R407~410 VRS-TV2AB123J J AA 12 kohms,1/10W
R411 VRD-ST2EE331J J AA 330 ohms,1/4W
R412 VRS-TV2AB103J J AA 10 kohm,1/10W
R413 VRD-ST2CD103J J AA 10 kohm,1/6W
R415,416 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R417,418 VRS-TV2AB223J J AA 22 kohms,1/10W
R419,420 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R421,422 VRS-TV2AB102J J AA 1 kohm,1/10W
R425~428 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
R429,430 VRD-ST2EE221J J AA 220 ohms,1/4W
R431,432 VRS-TV2AB153J J AA 15 kohms,1/10W
R433 VRD-ST2CD153J J AA 15 kohms,1/6W
R507 VRS-TV2AB473J J AA 47 kohms,1/10W
R508 VRS-TV2AB392J J AA 3.9 kohms,1/10W
R509 VRS-TV2AB331J J AA 330 ohms,1/10W
R510 VRS-TV2AB104J J AA 100 kohm,1/10W
R511 VRD-ST2CD103J J AA 10 kohm,1/6W
R512 VRS-TV2AB103J J AA 10 kohm,1/10W
R513,514 VRD-ST2CD103J J AA 10 kohm,1/6W
R519 VRD-ST2CD103J J AA 10 kohm,1/6W
R520,521 VRS-TV2AB563J J AA 56 kohms,1/10W
R522,523 VRD-ST2CD103J J AA 10 kohm,1/6W
R524 VRD-ST2CD472J J AA 4.7 kohms,1/6W
OTHER CIRCUITRY PARTS
CN101 92L3421-180003 J Connector Ass’y,3Pin
CN201 92L3421-882001 J Connector Ass’y,3Pin
CN202 92L3421-879001 J Connector Ass’y,5Pin
CN203 92L3461-000076 J Flat Wire,6Pin
CN204 92L3461-000078 J Flat Wire,7Pin
CN205A/B 92L3421-887002 J Connector Ass’y,7/7Pin
CN206 92L3471-000021 J Connector Ass’y,2Pin
CN501 92L3421-417002 J Plug,2Pin
CN502 92L3421-880001 J Connector Ass’y,13Pin
CON101 92L3101-171010 J AB Plug,3Pin
CON201 92L3101-171010 J AB Plug,3Pin
CON202 92L3101-171008 J AB Plug,5Pin
CON401 92L3301-008001 J Terminal,Speaker
CON501 92L3101-094001 J AB Connector Ass’y,2Pin
CON502 92L3101-171012 J Plug,13Pin
1 F601 92L5301-025002 J Fuse,T4A L 250V
JK201 92L3202-036002 J Jack,Mic
JK202 92L3201-080001 J Jack,LINE Input
JK401 92L3202-036001 J Jack,Headphones
M1(246-10) 92L195912301 J Motor with Pulley [Tape]
MIC1 92L7201-002001 J AG Built-in Microphone
1 SO601 92L3204-017001 J Socket,AC Inlet
SW1(245-11) 92L54030204 J Switch,Slide Type
[Tape 2 Direction]
SW2(245-12) 92L4110-011002 J Switch,Leaf Type [Tape 1 Play]
SW3(245-13) 92L4110-011001 J Switch,Leaf Type
[Tape 1 FF/REW]
SW4(245-14) 92L4110-011003 J Switch,Leaf Type [Tape 1 Rec]
SW5(245-15) 92L4110-011001 J Switch,Leaf Type [Tape 2 Play]
SW6(245-16) 92L4110-011001 J Switch,Leaf Type
[Tape 2 FF/REW]
SW101 92L4103-022001 J AF Switch,Slide Type
[Band Selector]
SW202 92L4103-025001 J Switch,Slide Type [Beat Cancel]
SW203 92L4103-025002 J Switch,Slide Type
[Dubbing Speed/Mic/FM Mode]
SW401 92L4104-002001 J AF Switch,Push Type [Surround]
SW501 92L4103-025003 J Switch,Slide Type
[Function Selector/Power]
1 SW601 92L4106-011001 J AH Switch,Slide Type
[Voltage Selector]
CABINET PARTS
201 92L20021000101 J Front Cabinet [WF-2100W (S)]
201 92L20021000103 J Front Cabinet [WF-2100W (BK)]
202 92L20221000101 J Rear Cabinet [WF-2100W (S)]
202 92L20221000102 J Rear Cabinet [WF-2100W (BK)]
203 92L21021000101 J Battery Compartment Lid
[WF-2100W (S)]
203 92L21021000102 J Battery Compartment Lid
[WF-2100W (BK)]
204 92L21121000101 J Cassette Holder [Tape 1]
[WF-2100W (S)]
204 92L21121000102 J Cassette Holder [Tape 1]
[WF-2100W (BK)]
205 92L21121000201 J Cassette Holder [Tape 2]
[WF-2100W (S)]
205 92L21121000202 J Cassette Holder [Tape 2]
[WF-2100W (BK)]
206 92L23021000101 J Panel,Display
207 92L24021000101 J Dial Pointer
208 92L24821000101 J Handle [WF-2100W (S)]
208 92L24821000102 J Handle [WF-2100W (BK)]
209 92L26021000101 J Window,Dial Pointer
210 92L26121000101 J Panel,Cassette Holder [Tape 1]
211 92L26721000101 J Lens,Volume Knob
212 92L27021000101 J Knob,Tuning
213 92L27021000201 J Knob,Fine Tuning
214 92L27221000A01 J Button,F FWD [Tape 2]
[WF-2100W (S)]
214 92L27221000A02 J Button,F FWD [Tape 2]
[WF-2100W (BK)]
215 92L27221000B01 J Button,Stop/Eject [Tape 2]
[WF-2100W (S)]
215 92L27221000B02 J Button,Stop/Eject [Tape 2]
[WF-2100W (BK)]
216 92L27221000C01 J Button,Direction [Tape 2]
[WF-2100W (S)]
216 92L27221000C02 J Button,Direction [Tape 2]
[WF-2100W (BK)]
217 92L27221000101 J Button,Record [Tape 1]
[WF-2100W (S)]
217 92L27221000102 J Button,Record [Tape 1]
[WF-2100W (BK)]
218 92L27221000201 J Button,Play [Tape 1]
[WF-2100W (S)]
– 3 –
