Model WH-247D
REF. NO
PARTS CODE
DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 71P107 INSTRUCTION BOOK 1
1-2 71R100 SET PACKING CASE 1
1-3 71R101 CARTON BOX 1
1-4 71R102 NAME PLATE 1
1-5 71P104 WIRING DIAGRAM STICKER 1
1-6 71J105 LOWER PAD 1
1-7 71J106 UPPER PAD 1
MECHANICAL PARTS
2-1 71R200SET BODY SET 1
2-2 71M219 GUIDE PIN 2
2-3 71M212 POWER SW. BUTTON 1
2-4 71M307 GUIDE PIN SPRING 1
2-5 71J203 ELB KNOB 1
2-6 7N6182 BREAKER ANGLE SUPPORT 1
2-7 7N706 SPLIT PIN 1
2-8 71J214 BREAKER LOCK 2
2-9 7A220 CLAMPING SPRING 2
2-10 7K102 WATER OUTLET 1
2-11 7D9241 PLUG 2
2-12 71J201 BACK COVER 1
2-13 7D601 AC LINE CLAMP 1
2-14 7N608 RUBBER CAP 1
2-15 71M216SET PUSH SWITCH SET 1
2-16 71M410ASY BODY VALVE ASS’Y 1
2-17 71J305 HEATER TANK SUPPORT 1
2-18 71N301SET HEATER TANK SET 1
2-19 71J306 CABLE TIES 1
2-20 71A204ASY SHOWER ASS’Y 1
2-21 7A901ASY SHOWER HOSE ASS’Y 1
2-22 7A910 SHOWER STAND 1
2-23 7G801ASY WATER INLET BODY ASS’Y 1
2-24 7A912 O-RING FIXER 1
ELECTRIC PARTS
3-1 7A605 BREAKER 220V, 30A 1
3-2 7J625 PCB CONTROL 1
3-3 7H630 CONNECTING WIRE FOR PCB 1
3-4 7U626 DISPLAY BOARD 1
3-5 71N411 BREAKER LEAD WIRE BLACK 1
3-6 7D2101 MICRO SWITCH 1
3-7 7R405 REED SWITCH ASS’Y 1
3-8 71R412 LEAD WIRE FOR PCB - A CN3 1
3-9 71K407 TRIAC LEAD WIRE BROWN 1
3-10 7R128ASY THERMISTOR ASS’Y 1
3-11 7N1261 THERMOSTAT 85
o
C1
3-12 71N410 THERMOSTAT LEAD WIRE YELLOW 1
3-13 7J127ASY TRIAC ASS’Y 600V, 25A 1
3-14 7P509 LEAD WIRE EARTH 1
