Sharp XL-HF201P Service Manual

XL-HF201P
3 – 2
Figure 5
Figure 7
Figure 8
Figure 9
CAUTION:
TO REMOVE SPEAKER UNIT, PRESS THESE LOCKING TABS
TO RELEASE SPEAKER WIRES.
SPEAKER UNIT
LOCKING
TAB
LOCKING TAB
SPEAKER
WIRE
STEP REMOVAL PROCEDURE FIGURE
1 Woofer
1. Net Frame Ass'y .......(A1) X 1
2. Screw........................(A2) X 4
3. Screw........................(A3) X 4
4. Woofer Ring..............(A4) X 1
7
7
8
8
2
Dome-Tweeter
1. Screw........................(B1) X 4
2. Tweeter Ring ............(B2) X 1
2. Screw........................(B3) X 4
8
8
9
(H1)x1
(H2)x1
(H3)x1
Display PWB
Front Panel Assy
(H4)x3
M2.6x8mm
Key/Jack PWB
(J1)x4
M2.6x8mm
(K1)x1
M2.6x8mm
USB PWB
Figure 6
(A1)x1
Net Frame Ass’y
Front Board Ass’y
Speaker Box
(A2)x4
Special Screw
Front Board Ass’y
Tweeter
(B1)x4
M3.5x14mm
Woofer
(B3)x4
M3.5x14mm
Front Board
Tweeter
(A4)x1
Woofer Ring
(B2)x1
Tweeter Ring
(A3)x4
M3.5x14mm
(L3)x2
M3x8mm
(L1)x1
Copper Sheet
(L2)x1
iPod Cover
iPod PWB
Top Cabinet
